1932-0 - Briggs & Stratton PRO 4,000 Watt Portable Generator Control Panel Parts Diagram

PRO 4,000 Watt Portable Generator

Control Panel Parts Diagram

  • Title

1

Briggs & Stratton B192832GS

PANEL, Control

$

$

Not available

2

Briggs & Stratton B192835GS

BOX, Control Panel

$136.99

$

Usually ships in 2-12 days

0

3

WASHER, #10 - M5

Note: (Purchase Locally)

$

$

Not available

4

WASHER, Lock, M5

Note: (Purchase Locally)

$

$

Not available

5

SCREW, M5 - 0.8 x 12

Note: (Purchase Locally)

$

$

Not available

6

WASHER, M6 - 1/4, Int. Shakeproof

Note: (Purchase Locally)

$

$

Not available

7

Briggs & Stratton 82538GS

SWITCH, Rocker

$6.99

$

Usually ships in 2-12 days

0

8

Briggs & Stratton 90418GS

OUTLET, 12VDC, Snap

$

$

Not available

9

Briggs & Stratton 77604GS

METER, Hour

$112.99

$

Usually ships in 2-12 days

0

10

WASHER, Lock, M3

Note: (Purchase Locally)

$

$

Not available

11

NUT, M3 - 0.5

Note: (Purchase Locally)

$

$

Not available

12

SCREW, M3 - 0.5 x 10

Note: (Purchase Locally)

$

$

Not available

13

Briggs & Stratton 22694GS

HOUSING, Receptacle

$5.99

$

Usually ships in 2-12 days

0

14

Briggs & Stratton 87962GS

BREAKER, Circuit, 12V, 10A

$29.99

$

Usually ships in 2-12 days

0

15

Briggs & Stratton 84028GS

TRANSFORMER, Idle Cnt

$47.99

$

In Stock, only 2 left!

0

16

Briggs & Stratton 64525GS

STANDOFF, Hex

$5.49

$

Usually ships in 2-12 days

0

17

Briggs & Stratton 193362GS

PCB, Idle Control

$164.99

$

Usually ships in 2-12 days

0

18

SCREW, #6-32 x 3/8

Note: (Purchase Locally)

$

$

Not available

19

Briggs & Stratton B5052GS

STRIP,Terminal

$8.49

$

Usually ships in 2-12 days

0

20

WASHER, Lock, M4

Note: (Purchase Locally)

$

$

Not available

21

SCREW, M4 - 0.7 x 16

Note: (Purchase Locally)

$

$

Not available

22

NUT, M4 - 0.7

Note: (Purchase Locally)

$

$

Not available

23

WASHER, M4

Note: (Purchase Locally)

$

$

Not available

24

Briggs & Stratton 192931GS

BRACKET, GFCI Breaker

$46.99

$

Usually ships in 2-12 days

0

25

WASHER, Shakeproof, Int. #8

Note: (Purchase Locally)

$

$

Not available

26

Briggs & Stratton 192828BGS

BREAKER, Circuit, GFCI, 20A

$185.99

$

Usually ships in 2-12 days

0

27

Briggs & Stratton 68868GS

OUTLET, 120V, 30A
(Superseded to 705932)

$37.99

$

Usually ships in 2-12 days

0

28

Briggs & Stratton 68867GS

OUTLET, 120/240V, 20A

$46.99

$

Usually ships in 2-12 days

0

29

Briggs & Stratton 68759GS

OUTLET, 120V, 20A, Duplex

$24.99

$

In Stock, only 2 left!

0

30

Briggs & Stratton 193036GS

HARNESS,Wire

$54.99

$

Usually ships in 2-12 days

0

31

Briggs & Stratton 46669GS

JUMPER,Terminal Block

$1.99

$

Usually ships in 2-12 days

0
