3341 - International Harvester 21" Self-Propelled Walk-Behind Mower (1977 - 1983) Mower Housing, Cutting Blade, Rear Shield And Rear Wheels Parts Diagram

21" Self-Propelled Walk-Behind Mower

Mower Housing, Cutting Blade, Rear Shield And Rear Wheels Parts Diagram

  • Title

1

Cub Cadet IH-73511-C1

HOUSING, MOWER

$

$

Currently unavailable

2

Cub Cadet IH-73513-C1

DEFLECTOR

$

$

Currently unavailable

3

Cub Cadet IH-73514-C1

SPRING, HINGE

$

$

Currently unavailable

4

Cub Cadet IH-73191-C1

SCREW

$

$

Not available

5

Cub Cadet IH-73517-C1

SCREW

$

$

Currently unavailable

6

Cub Cadet IH-73518-C1

SHIELD, REAR

$

$

Not available

7

Cub Cadet IH-73519-C1

PLUG, WASH-OUT

$

$

Currently unavailable

8

Cub Cadet IH-73521-C1

BOLT, WHEEL

$

$

Not available

9

Cub Cadet IH-73523-C1

NUT, LOCK

$

$

Currently unavailable

10

Cub Cadet IH-73524-C1

ARM, PIVOT -RIGHT REAR-

$

$

Currently unavailable

11

Cub Cadet IH-73525-C1

ARM, PIVOT -LEFT REAR-

$

$

Not available

12

Cub Cadet IH-71961-C1

WASHER

$

$

Currently unavailable

13

Cub Cadet IH-73527-C1

ARM, SPRING

$

$

Not available

14

Cub Cadet IH-73528-C1

KNOB, ARM

$

$

Currently unavailable

15

Cub Cadet IH-73529-C1

BOLT, PIVOT

$

$

Currently unavailable

16

Cub Cadet IH-73530-C1

NUT, 5/16-1B

$

$

Currently unavailable

17

Cub Cadet IH-73532-C1

LATCH, HANDLE

$

$

Currently unavailable

18

Cub Cadet IH-73533-C1

SPACER, HANDLE LATCH

$

$

Currently unavailable

19

Cub Cadet IH-79723-C1

BOLT, SHOULDER

Note: (SERIAL NO. 13851 THRU 15451 ONLY)

$

$

Currently unavailable

19

Cub Cadet IH-73534-C1

SCREW, SHOULDER

Note: (SERIAL NO. 13850 & BELOW, SERIAL NO. 15452 & ABOVE)

$

$

Not available

20

Cub Cadet IH-73535-C1

WHEEL W/TIRE, REAR

$

$

Currently unavailable

21

Cub Cadet IH-73807-C1

PULLEY, DRIVE

$

$

Currently unavailable

23

Cub Cadet IH-73538-C1

RETAINER, BLADE

$

$

Currently unavailable

24

Cub Cadet IH-626803-R1

KEY, 3/16 X .50 SQ PARALLEL
(Superseded to 714-3009)

$3.99

$

Usually ships in 3-6 days

0

25

Cub Cadet IH-73539-C1

BLADE, 21 IN. CUTTING

$

$

Not available

26

Cub Cadet IH-73541-C1

CLIP, ANTI-SCALP

$

$

Not available

27

Cub Cadet IH-103328

WASHER, 7/16 PLN HV LOCK

$

$

Currently unavailable

28

Cub Cadet IH-73542-C1

BOLT, BLADE

$

$

Currently unavailable

29

Cub Cadet IH-73634-C1

BRACKET, ADJUSTING

$

$

Currently unavailable

Cub Cadet IH-73635-C1

WASHER, 5/16

$

$

Currently unavailable

Cub Cadet IH-180018

BOLT, 1/4 X 5/8 TYPE 5
(Superseded to 710-0751)

$3.99

$

In Stock, Qty 20+

0

Cub Cadet IH-156417

SCREW, 5/16 X 5/8 ZNP F/HDCR MACH

$

$

Currently unavailable

30

Cub Cadet IH-73536-C1

COVER, DRIVE BELT

$

$

Currently unavailable

Cub Cadet IH-64981-C1

SCREW, DRIVE BELT COVER

$

$

Currently unavailable

Cub Cadet IH-73500-C91

PACKAGE, PRODUCT GRAPHICS

Note: (CONSISTS OF THE FOLLOWING 6 ITEMS)

$

$

Currently unavailable

Cub Cadet IH-73501-C1

PRODUCT GRAPHIC, DANGER - WHIRLING BLADE

Note: (3340 AND 3341 MOWERS)

$

$

Currently unavailable

PRODUCT GRAPHIC, INTERNATIONAL NAME TRADEMARK

Note: (3340 AND 3341 MOWERS, NOT AVAILABLE FOR SERVICE)

$

$

Not available

Cub Cadet IH-73503-C1

PRODUCT GRAPHIC, CAUTION AND STARTING INSTRUCTIONS

Note: (3340 MOWER)

$

$

Currently unavailable

Cub Cadet IH-73504-C1

PRODUCT GRAPHIC, CAUTION AND STARTING INSTRUCTIONS

Note: (3341 MOWER)

$

$

Currently unavailable

Cub Cadet IH-73505-C1

PRODUCT GRAPHIC, CAUTION AND STARTING INSTRUCTIONS

Note: (3342 MOWER)

$

$

Currently unavailable

PRODUCT GRAPHIC, INTERNATIONAL NAME TRADEMARK -ON BELT COVER-

Note: (3342 MOWER, NOT AVAILABLE FOR SERVICE)

$

$

Not available

Cub Cadet IH-77581-C91

PACKAGE, IH TRADEMARK PRODUCT GRAPHICS -SMALL SIZE-

Note: (CONSISTS OF THE FOLLOWING 3 ITEMS)

$

$

Not available

IH TRADEMARK 1.46 X 1.57

Note: (NOT AVAILABLE FOR SERVICE)

$

$

Not available

IH TRADEMARK 2 19 X 2.36

Note: (NOT AVAILABLE FOR SERVICE)

$

$

Not available

IH TRADEMARK 2.93 X 3.15

Note: (NOT AVAILABLE FOR SERVICE)

$

$

Not available
