38025 (1800) - Toro Power Curve Snow Thrower (SN: 000000001 - 000999999) (1990) CHUTE ASSEMBLY Parts Diagram

Power Curve Snow Thrower

CHUTE ASSEMBLY Parts Diagram

  • Title

1

Toro 73-0340

Bar-Switch
(Superseded to 100-1212)

$

$

Not available

2

Toro 64-4930

SWITCH
(Superseded to 107-3323)

$16.99

$

In Stock, Qty 9

0

3

Toro 73-0320

UPPER CONTROL HANDLE

$

$

Not available

4

Toro 73-0360

KEY - 1800

$

$

Not available

5

Toro 73-0330

1800 L CNTRL HANDLE

$

$

Not available

6

Toro 73-0350

SPRING, INTERLOCK

$

$

Not available

7

Toro 32104-121

Screw
(Superseded to 94-4496)

$1.49

$

In Stock, Qty 20+

0

8

Toro 73-0420

Cord-Supply

$

$

Not available

9

Toro 73-0290

TUBE-UPPER HANDLE

$87.99

$

Usually ships in 3-6 days

0

10

Toro 32112-1

PUSHNUT-CAP, WASHER

$6.49

$

Usually ships in 3-6 days

0

11

Toro 73-0251

Sleeve-Crank, Chute

$

$

Not available

12

Toro 33-8951

Screw-HH

$1.49

$

In Stock, Qty 10

0

13

Toro 3296-12

NUT-LOCK, NI

$1.49

$

In Stock, Qty 12

0

14

Toro 73-0490

DECAL - ESCUTCHEON

$

$

Not available

15

Toro 73-0240

Rod-Crank, Chute

$30.99

$

Usually ships in 3-6 days

0

16

Toro 73-0230

Gear-Crank, Chute

$9.49

$

Usually ships in 3-6 days

0

17

Toro 73-0310

Plate-Escutcheon
(Superseded to 73-0310-03)

$

$

Not available

18

Toro 256-306

Bushing-Nyliner

$1.49

$

In Stock, Qty 9

0

1

Toro 73-0190

Chute-Deflector

$27.99

$

Usually ships in 3-6 days

0

2

Toro 3256-68

WASHER-FLAT

$2.99

$

In Stock, Qty 20+

0

3

Toro 3296-29

NUT-LOCK, NI

$2.49

$

In Stock, Qty 20+

0

4

Toro 73-0260

Handle-Middle

$

$

Not available

5

Toro 32104-121

Screw
(Superseded to 94-4496)

$1.49

$

In Stock, Qty 20+

0

6

Toro 20-4320

WASHER-RUBBER

$0.99

$

In Stock, Qty 10

0

7

Toro 73-0180

Chute-Lower

$39.99

$

Usually ships in 3-6 days

0

8

Toro 3230-22

SCREW-CARR

$2.49

$

In Stock, Qty 20+

0
