CZ 4817 KOA (968999220) - Husqvarna 48" Zero-Turn Mower (2003-05) HANDLE & CONTROLS 2 Parts Diagram

48" Zero-Turn Mower

HANDLE & CONTROLS 2 Parts Diagram

  • Title

19

Husqvarna 539102436

BATTERY, 12 V 330 AMP
(Superseded to 579411601)

$

$

Not available

6

Husqvarna 539101949

E-RING 1/2 (2 2)

$3.99

$

Usually ships in 3-10 days

0

2

Husqvarna 539107530

BATTERY SUPPORT-RH

$34.99

$

Usually ships in 3-10 days

0

27

Husqvarna 539990563

HCS 3/8-16X1.GRD.5.ZD

$1.49

$

Usually ships in 3-10 days

0

26

Husqvarna 539976937

HCS 5/16-18X2

$3.99

$

Usually ships in 3-10 days

0

20

Husqvarna 539109334

LOWER SWIVEL

$36.99

$

Usually ships in 3-10 days

0

13

Husqvarna 539102678

TAPPED PLATE

$15.99

$

In Stock, only 4 left!

0

14

Husqvarna 539107526

CONTROL LEVER-BLACK
(Superseded to 539108254)

$

$

Not available

22

Husqvarna 539107623

CABLE-RH
(Superseded to 539110044)

$

$

Not available

31

Husqvarna 539102828

SCREW, 5/16 X 5/8 SHOULDER

$4.99

$

Usually ships in 3-10 days

0

25

Husqvarna 539102593

WASHER, 3/8 DISC SPRING SPEC

$3.99

$

Usually ships in 3-10 days

0

9

Husqvarna 539976438

COMPRESSION SPRING

$4.99

$

Usually ships in 3-10 days

0

11

Husqvarna 539105036

GRIP, PARK BRAKE

$6.49

$

In Stock, only 1 left!

0

36

Husqvarna 539108663

UPPER CABLE END

$27.99

$

Usually ships in 3-10 days

0

30

Husqvarna 539102827

SPACER

$6.49

$

In Stock, only 2 left!

0

16

Husqvarna 539107629

PUSH NUT-NYLON

$4.99

$

In Stock, Qty 7

0

15

Husqvarna 539102592

GRIP

$

$

Not available

3

Husqvarna 539107568

CONTROL PIVOT SHAFT

$

$

Not available

18

Husqvarna 539107628

BATTERY HOLD DOWN

$10.99

$

In Stock, only 4 left!

0

21

Husqvarna 539107592

BRAKE CABLE

$103.99

$

Usually ships in 3-10 days

0

37

Husqvarna 539990188

FLAT WASHER 5/16 SAE
(Superseded to 819111116)

$3.99

$

In Stock, Qty 20+

0

29

Husqvarna 539107475

BOLT 5/16-18 X 3/4

$6.49

$

In Stock, Qty 5

0

33

Husqvarna 539108072

DAMPENER BRACKET

$8.99

$

Usually ships in 3-10 days

0

4

Husqvarna 539990692

WASHER 5/16 FLAT
(Superseded to 819121414)

$3.49

$

In Stock, Qty 20+

0

34

Husqvarna 539108120

JAM NUT 1/4C (2 2 PW01)

$3.99

$

In Stock, only 2 left!

0

32

Husqvarna 539108793

DAMPENER

$

$

Not available

23

Husqvarna 539107624

CABLE-LH
(Superseded to 539110045)

$303.99

$

Usually ships in 3-10 days

0

8

Husqvarna 539107576

UPPER BRAKE LEVER

$17.99

$

Usually ships in 3-10 days

0

12

Husqvarna 539976952

SCREW #10-24 X 5/8
(Superseded to 596039001)

$3.99

$

In Stock, Qty 20+

0

35

Husqvarna 539103547

WASHER

$0.99

$

In Stock, only 2 left!

0

10

Husqvarna 539101080

SWITCH, INTERLOCK

$7.49

$

In Stock, Qty 20+

0

1

Husqvarna 539107528

BATTERY SUPPORT-LH

$34.99

$

Usually ships in 3-10 days

0

28

Husqvarna 539990717

NUT 5/16 NYLOC
(Superseded to 596583702)

$3.99

$

In Stock, Qty 20+

0

5

Husqvarna 539100032

BUSHING, FLANGED NYLON

$

$

Not available

17

Husqvarna 539107632

BOLT - 1/4-20 X 7.5

$

$

Not available

24

Husqvarna 539976988

HAIRPIN #2

$3.99

$

Usually ships in 3-10 days

0

7

Husqvarna 539107603

BRAKE LEVER

$7.49

$

Usually ships in 3-10 days

0
