F 160Z (5901536) - Ferris F160Z Series 48" Zero-Turn Mower, 24hp Kawasaki, CARB Evap Canister Group - CAL Models Parts Diagram

F160Z Series 48" Zero-Turn Mower, 24hp Kawasaki, CARB

Evap Canister Group - CAL Models Parts Diagram

  • Title

1

Ferris 313036

CNSTR, CARB, 6 GAL
(Superseded to 313036GS)

$217.99

$

Usually ships in 2-12 days

0

2

Ferris 5103062

FITTING, 3/16" TEE, BARB TYPE, HDPE
(Superseded to 5103062YP)

$10.99

$

Usually ships in 2-12 days

0

3

Ferris 7700552X7P5

HOSE, VAPOR, 5MM ID, 7.50 LG

$

$

Currently unavailable

4

Ferris 7700552X49

HOSE, VAPOR, 5MM ID, 49.00 LG

Note: (Kawasaki Models)

$

$

Currently unavailable

5

Ferris 7700552X16P5

HOSE, VAPOR, 5MM ID, 16.50 LG

Note: (Kawasaki Models)

$

$

Currently unavailable

6

Ferris 7700552X18

HOSE, VAPOR, 5MM ID, 18.00 LG
(Superseded to 7700552X18FS)

Note: (Kawasaki Models)

$4.49

$

Usually ships in 2-12 days

0

7

Ferris 5025394

NUT, 3/8-16 HEX NYLOCK FLANGE
(Superseded to 5025394SM)

$4.49

$

In Stock, Qty 15

0

8

Ferris 5414302A

BRACKET, EVAP MOUNT, LEFT - BLK

$

$

Currently unavailable

9

Ferris 5414303A

BRACKET, EVAP MOUNT, RIGHT - BLK

$

$

Currently unavailable

10

Ferris 5103055

CLAMP, 3" ID, CUSHIONED, STAINLESS
(Superseded to 5103055YP)

$7.99

$

Usually ships in 2-12 days

0

11

Ferris 5025299X6

USE 5106757 - SCREW,1/4-20X3/4, ZINC
(Superseded to 5106757)

$3.49

$

Usually ships in 2-12 days

0

12

Ferris 5025013X10

BOLT, 3/8-16 X 1-1/4" GD5 CZ
(Superseded to 5025013X10SM)

$3.99

$

Usually ships in 2-12 days

0

13

Ferris 5025156

WASHER, 3/8 SAE
(Superseded to 5025156FS)

$3.49

$

Usually ships in 2-12 days

0

14

Ferris 5025391

NUT, 1/4-20 HEX NYLOCK FLANGE
(Superseded to 5025391FS)

$3.99

$

Usually ships in 2-12 days

0

15

Ferris 5103092

HOSE, FORMED, EVAP CANISTER
(Superseded to 5103092YP)

$33.99

$

Usually ships in 2-12 days

0

16

Ferris 5103080

FITTING, STRAIGHT, 10MMX10MM, PLASTIC
(Superseded to 5103080YP)

$3.49

$

Usually ships in 2-12 days

0

17

Ferris 5023268

CLAMP, HOSE
(Superseded to 5023268SM)

$3.49

$

In Stock, only 2 left!

0

18

Ferris 5100772

TIE, SELF-LOCKING, 15"

$

$

Currently unavailable

19

Ferris 1752800

DUST FILTER, CANISTER
(Superseded to 1752800YP)

Note: (SV)

$15.99

$

Usually ships in 2-12 days

0

20

Ferris 770046

REMOTE VENT ASSEMBLY

Note: (SV)

$16.99

$

In Stock, only 2 left!

0

21

Ferris 209043

GROMMET
(Superseded to 799624)

Note: (SV)

$8.99

$

In Stock, only 3 left!

0

22

Ferris 5021029

TIE, SELF-LOCKING, 12"
(Superseded to 5021029SM)

$

$

Not available

23

Ferris 7700552X50P5

HOSE, VAPOR, 5 MM ID, 50.50 LG

Note: (Briggs & Stratton Models)

$

$

Currently unavailable

24

Ferris 7700552X29

HOSE, VAPOR, 5 MM ID, 29.00 LG
(Superseded to 7700552X29YP)

Note: (Briggs & Stratton Models)

$7.49

$

Usually ships in 2-12 days

0

25

Ferris 7700552X9

HOSE, VAPOR, 5 MM ID, 9.00 LG

Note: (Briggs & Stratton Models)

$

$

Currently unavailable
