HydroDrive (5900806) - Ferris HydroDrive Series 48" Walk-Behind Mower, 16hp Motion Control Group - Upper (S/N: 2013394099 & Above) Parts Diagram

HydroDrive Series 48" Walk-Behind Mower, 16hp

Motion Control Group - Upper (S/N: 2013394099 & Above) Parts Diagram

  • Title

1

Ferris 7090095

HN, 1/4F GR5 YZ
(Superseded to 7090095FS)

$3.49

$

Usually ships in 2-12 days

0

2

Ferris 5025154

WASHER, 1/4 SAE
(Superseded to 84007033)

$4.49

$

Usually ships in 2-12 days

0

3

Ferris 5025010X6

BOLT, 1/4-20 X 3/4 GD5 YZ
(Superseded to 5025010X6SM)

$3.99

$

In Stock, Qty 13

0

4

Ferris 5025391

NUT, 1/4-20 HEX NYLOCK FLANGE
(Superseded to 5025391FS)

$3.99

$

Usually ships in 2-12 days

0

5a

Ferris 5407391A

LEVER, REVERSE HANDLE - BLK

Note: (S/N: 2014663599 - 2015332626)

$11.99

$

Usually ships in 2-12 days

0

5b

Ferris 5101287A

LEVER, REVERSE HANDLE - BLK

Note: (S/N: 2014663598 & Below)

$10.99

$

Usually ships in 2-12 days

0

6

Ferris 5101673

ROD, REVERSING, HD1648
(Superseded to 5101673FS)

$13.99

$

Usually ships in 2-12 days

0

7

Ferris 5023212

NUT, 5/16-24 HEX, LH
(Superseded to 5023212SM)

$3.49

$

Usually ships in 2-12 days

0

8

Ferris 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

9

Ferris 5025010X14

BOLT, 1/4-20 X 1-3/4" GD5 YZ
(Superseded to 5025010X14SM)

$3.99

$

In Stock, only 1 left!

0

10

Ferris 5025288

WASHER, 1/4" FENDER
(Superseded to 5025288YP)

$3.99

$

In Stock, Qty 5

0

11

Ferris 5022361

SPRING-COMP, .428IDX2.50LGX.154WR, BZ
(Superseded to 5022361SM)

$9.99

$

Usually ships in 2-12 days

0

12

Ferris 5025164

WASHER, 5/16" FENDER
(Superseded to 5025164SM)

$3.99

$

In Stock, only 1 left!

0

13

Ferris 5025013X20

BOLT, 3/8-16 X 2-1/2" GD5 CZ
(Superseded to 84007037)

$2.99

$

Usually ships in 2-12 days

0

14

Ferris 5010546

COLLAR, 3/8" SET
(Superseded to 5010546SM)

$5.99

$

Usually ships in 2-12 days

0

15

Ferris 5101676

ADJUSTER, ROD LINKAGE 5/16-24
(Superseded to 5101676FS)

$23.99

$

Usually ships in 2-12 days

0

16

Ferris 5025033

NUT, 5/16-24 HEX
(Superseded to 5025033FS)

$3.49

$

Usually ships in 2-12 days

0

17

Ferris 5042555

ROD, 5/16 X 13.75 TBE
(Superseded to 5042555SM)

$10.99

$

Usually ships in 2-12 days

0

18

Ferris 5020047

COLLAR, 5/16" SET
(Superseded to 5020047SM)

$7.49

$

Usually ships in 2-12 days

0

19

Ferris 5025212X7

PIN, CLEVIS, 1/4 X 7/8, PLATED
(Superseded to 5025212X7SM)

$4.99

$

Usually ships in 2-12 days

0

20

Ferris 84007748

CLEVIS

$13.99

$

Usually ships in 2-12 days

0

21

Ferris 5101242

ROD, OPC LINK, HD1648
(Superseded to 5101242FS)

$4.99

$

Usually ships in 2-12 days

0

22

Ferris 5025394

NUT, 3/8-16 HEX NYLOCK FLANGE
(Superseded to 5025394SM)

$4.49

$

In Stock, Qty 20+

0

23

Ferris 5403307B

WELD, REVERSE HANDLE - RH

Note: (S/N: 2015332626 & Below)

$

$

Currently unavailable

24

Ferris 5101215

SPACER, .26 X .38 X 1.250, YZ
(Superseded to 5101215YP)

$8.49

$

Usually ships in 2-12 days

0

25

Ferris 5025220

BOLT, 3/8-16 x 1-1/2", 1/2" SHOULDER
(Superseded to 5025220SM)

Note: (S/N: 2015332626 & Below)

$11.99

$

Usually ships in 2-12 days

0

26

Ferris 5025156

WASHER, 3/8 SAE
(Superseded to 5025156FS)

$3.49

$

Usually ships in 2-12 days

0

27

Ferris 5025097

NUT, 3/8-24 HEX NYLON LOCK
(Superseded to 5025097FS)

$2.49

$

Usually ships in 2-12 days

0

28

Ferris 5101236

ROD, CRUISE CONTROL, HD1648

$42.99

$

Usually ships in 2-12 days

0

29

Ferris 5403239B

WELD, OPC SHAFT- RED

$74.99

$

Usually ships in 2-12 days

0

30

Ferris 5104202A

NLA - FLAP, OPS - BLK

$28.99

$

Usually ships in 2-12 days

0

31

Ferris 5104201A

NLA - FLAP, OPS - BLK
(Superseded to 5104201AAFS)

$32.99

$

Usually ships in 2-12 days

0

32

Ferris 5101274

SPACER, .26 X .50 X 1.00 YZ
(Superseded to 5101274FS)

$5.49

$

Usually ships in 2-12 days

0

33

Ferris 5102701

SPACER, .34 X 1.54 X .25 UHMW
(Superseded to 5102701YP)

$3.99

$

In Stock, only 1 left!

0

34

Ferris 5403778

PLATE, FRICTION CONTROL

$14.99

$

Usually ships in 2-12 days

0

35

Ferris 5403776B

WELD, SPEED CONTROL,HD1648 - RED

$85.99

$

Usually ships in 2-12 days

0

36

Ferris 5100744

BAR, SPEED CONTROL, DIPPED

$59.99

$

Usually ships in 2-12 days

0

37

Ferris 5101245

SPACER, .38 X .75 X 1.25, YZ
(Superseded to 5101245YP)

$7.99

$

Usually ships in 2-12 days

0

38

Ferris 5022392

ROD END, 3/8-24 LH FEMALE
(Superseded to 5022392FS)

$24.99

$

Usually ships in 2-12 days

0

39

Ferris 5020805

BALL JOINT, 3/8-24 FEM, STUD.
(Superseded to 5020805FS)

$17.99

$

Usually ships in 2-12 days

0

40

Ferris 5403959B

WELD, REVERSE HANDLE - LH

Note: (S/N: 2015332626 & Below)

$34.99

$

Usually ships in 2-12 days

0

41

Ferris 5025055X10

BOLT, 5/16-18 X 1-1/4 GD5 TFL, CZ
(Superseded to 5025055X10YP)

$3.49

$

In Stock, only 1 left!

0

42

Ferris 5025155

WASHER, 5/16" SAE

$

$

Currently unavailable

43

Ferris 5104493

BALL JOINT 5/16-24 RH FEMALE BRONZE RACE
(Superseded to 5104493YP)

$18.99

$

In Stock, only 1 left!

0

44

Ferris 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

45

Ferris 5025211

PIN, HAIR, .0585 X 1-1/8, 1/4 EYE, YZ
(Superseded to 5025211SM)

$3.99

$

In Stock, only 1 left!

0

46

Ferris 5102556A

HANDLE, REVERSING - BLK
(Superseded to 5102556AAFS)

Note: (S/N: 2015332627 & Above)

$38.99

$

Usually ships in 2-12 days

0

47

Ferris 5025223

BOLT, 3/8-16 X 1, 1/2 SHOULDER
(Superseded to 5025223SM)

Note: (S/N: 2015332627 & Above)

$7.99

$

Usually ships in 2-12 days

0

48

Ferris 5020095

GREASE FITTING, 1/4-28 STRAIGHT
(Superseded to 5020095SM)

Note: (S/N: 2015332627 & Above)

$3.99

$

Usually ships in 2-12 days

0
