LSZ 5424 - Husqvarna 54" Zero-Turn Mower (2008-11) BRAKE / REAR MOWER LIFT Parts Diagram

54" Zero-Turn Mower

BRAKE / REAR MOWER LIFT Parts Diagram

  • Title

6

Husqvarna 522823602

SHAFT, LIFT, BLK
(Superseded to 574216602)

$

$

Not available

22

Husqvarna 510184802

BRAKE, RT, BLACK

$47.99

$

Usually ships in 3-10 days

0

24

Husqvarna 510207401

ROD, THRD, 3/8-24

$9.99

$

Usually ships in 3-10 days

0

19

Husqvarna 539112899

5/16-18 NYLOC FLANGE NUT
(Superseded to 594944401)

$4.99

$

In Stock, Qty 10

0

17

Husqvarna 510184901

PLASTIC NUT

$6.49

$

In Stock, Qty 9

0

26

Husqvarna 539990365

RP_COTTER PIN 1/8 X 3/4
(Superseded to 876020412)

$6.49

$

In Stock, Qty 20+

0

3

Husqvarna 510422901

ROD, HANDLE RELEASE

$

$

Not available

8

Husqvarna 510185301

LINK, REAR SUSPENSION
(Superseded to 587623001)

$12.99

$

In Stock, Qty 20+

0

18

Husqvarna 539105069

E-RING 5/8

$3.99

$

In Stock, Qty 7

0

4

Husqvarna 516008801

RB ROD, LATCH RELEASE
(Superseded to 583629301)

$6.49

$

Usually ships in 3-10 days

0

11

Husqvarna 532175994

NUT, LIFT LINK 7/16-20
(Superseded to 589464902)

$3.99

$

In Stock, Qty 20+

0

9

Husqvarna 522858601

ASSEMBLY, BRKT LINK
(Superseded to 587623001)

$12.99

$

In Stock, Qty 20+

0

10

Husqvarna 539101341

HCS 3/8C X 3

$4.99

$

In Stock, Qty 20+

0

7

Husqvarna 510207301

BUTTON, PUSH, BLACK

$4.99

$

In Stock, Qty 9

0

12

Husqvarna 532195185

ARM.SUSPENSION.MOWER

$18.99

$

Usually ships in 3-10 days

0

1

Husqvarna 510030701

SPRING, COMPRESSION

$

$

Not available

21

Husqvarna 539111690

SPACER

$12.99

$

In Stock, only 2 left!

0

27

Husqvarna 539990155

NUT 3/8F

$4.99

$

In Stock, Qty 16

0

29

Husqvarna 539990122

WASHER 3/8 SAE FLAT
(Superseded to 596565301)

$3.99

$

In Stock, Qty 20+

0

13

Husqvarna 532195161

STUD.FASTNER.W/ANTI-ROTATE

$

$

Not available

23

Husqvarna 510184702

BRAKE, LT, BLACK

$47.99

$

Usually ships in 3-10 days

0

2

Husqvarna 510207201

GRIP, HANDLE, BLACK 4"

$5.99

$

In Stock, Qty 10

0

15

Husqvarna 539990598

WASHER 1/4 FLAT

$

$

Not available

20

Husqvarna 539118762

SPRING

$

$

Not available

28

Husqvarna 510207501

YOKE, 3/8 SHORT

$3.99

$

Usually ships in 3-10 days

0

25

Husqvarna 539977703

CLEVIS PIN 3/8 X 1 1/8

$4.99

$

In Stock, Qty 14

0

16

Husqvarna 539976978

NUT.1/4-20.HEX.NYLOC.ZD
(Superseded to 595086601)

$3.99

$

Usually ships in 3-10 days

0

14

Husqvarna 539113621

SB 3/8-16 X 3/8 SKT HD ZD
(Superseded to 596241101)

$3.99

$

In Stock, only 4 left!

0

5

Husqvarna 522710802

SHAFT.ASSY.BRAKE.WLDMT.BLACK

$241.99

$

Usually ships in 3-10 days

0

30

Husqvarna 539200282

NUT HEX 3/8-16 NYLON, THIN

$

$

Not available
