TB 138 PS (41AC138C966) - Troy-Bilt Pole Saw, Electric Trimmer Assembly Parts Diagram

Pole Saw, Electric

Trimmer Assembly Parts Diagram

  • Title

1

MTD 753-04345

Upper Drive Shaft Housing Assembly

$

$

Not available

2

Troy-Bilt 753-06039

D-Handle Assembly (Incl. 3)

$11.99

$

In Stock, only 3 left!

0

3

Troy-Bilt 753-06040

Bolt

$6.99

$

In Stock, Qty 6

0

4

MTD 791-182928

Split boom Coupler (Incl. 5-8)

$

$

Not available

5

Troy-Bilt 791-182057

Screw

$4.49

$

In Stock, Qty 11

0

6

Troy-Bilt 791-181617

Bolt

$5.49

$

In Stock, Qty 13

0

7

MTD 791-181618B

Adjustment Knob (Incl. 13)
(Superseded to 791-181981)

$7.49

$

In Stock, only 1 left!

0

8

Troy-Bilt 712-04018A

Knob Retaining Nut

$4.49

$

In Stock, Qty 6

0

9

Troy-Bilt 791-610327

Shoulder Strap Spring

$32.99

$

Usually ships in 3-6 days

0

10

Troy-Bilt 753-04508

Lower Drive Shaft Housing Assembly

$80.99

$

In Stock, Qty 8

0

11

Troy-Bilt 753-04282

Shield Mounting Hardware

$25.99

$

In Stock, only 3 left!

0

12

Troy-Bilt 753-04283

Shield Assembly (Incl. 11 & 13)

$50.99

$

In Stock, only 3 left!

0

13

Troy-Bilt 791-180553

Blade Assembly

$14.99

$

In Stock, only 1 left!

0

14

Troy-Bilt 753-04284

Outer Spool Assembly (Incl. 15)

$28.99

$

In Stock, Qty 20+

0

15

Troy-Bilt 791-610660

Retainer

$4.99

$

In Stock, Qty 20+

0

16

Troy-Bilt 791-610317B

Spring

$10.99

$

In Stock, Qty 20+

0

17

Troy-Bilt 753-1155

Inner Reel

$22.99

$

In Stock, Qty 20+

0

18

Troy-Bilt 791-153066B

Bump Head Knob Assembly

$13.99

$

In Stock, Qty 20+

0
