20526 C - Toro Walk-Behind Mower (SN: 009000001 - 009999999) (1989) ENGINE ASSEMBLY Parts Diagram

Walk-Behind Mower

ENGINE ASSEMBLY Parts Diagram

  • Title

1

Toro 12-2699

Housing (Incl. Ref. #2)
(Superseded to 11-4069)

$1081.99

$

Usually ships in 3-6 days

0

2

Toro 56-6270

DECAL-DANGER

$8.49

$

Usually ships in 3-6 days

0

3

Toro 46-6810

SCREW AND WASHER ASM

$5.49

$

In Stock, only 3 left!

0

4

Toro 11-6239

Tunnel-Discharge (Incl. Ref. #5)
(Superseded to 116239-01)

$

$

Not available

5

Toro 62-4060

DECAL - DANGER

$

$

Not available

6

Toro 51-0201

Discharge Door Assembly
(Superseded to 77-0200)

$

$

Not available

7

Toro 33-5840

Retainer-Door

$

$

Currently unavailable

8

Toro 33-4860

TORSION SPRING

$69.99

$

Usually ships in 3-6 days

0

9

Toro 43-4840

DOOR SPACER

$7.49

$

Usually ships in 3-6 days

0

10

Toro 46-8091

SCREW-HWH

$3.99

$

In Stock, Qty 20+

0

11

Toro 42-4010

SAFETY LATCH

$

$

Not available

12

Toro 46-6811

SCREW-HWH

$3.49

$

In Stock, Qty 7

0

13

Toro 23-1040

DOOR LATCH PLATE

$

$

Not available

14

Toro 46-8090

SCREW-PLASTITE

$

$

Not available

15

Toro 2412-83

CLAMP-CABLE

$

$

Not available

16

Toro 12-5450

SCREW

$8.99

$

In Stock, only 2 left!

0

17

Toro 44-0580

SHIELD-TRAILING
(Superseded to 112-9989)

$27.99

$

In Stock, Qty 16

0

18

Toro 33-3208

ROD-SHIELD

$14.99

$

In Stock, Qty 16

0

19

Toro 25-7740

KNOB-ARM

$4.99

$

In Stock, Qty 13

0

20

Toro 44-5270

PIVOT SCREW

$8.99

$

In Stock, Qty 13

0

21

Toro 11-9509

Wheel & Tire Assembly (Inc. Ref. #22)
(Superseded to 51-2751)

$30.99

$

In Stock, only 4 left!

0

22

Toro 27-6250

BUSHING

$2.99

$

In Stock, Qty 20+

0

23

Toro 27-6230

BOLT-WHEEL

$8.49

$

In Stock, only 3 left!

0

24

Toro 40-1940

WASHER

$2.99

$

In Stock, Qty 20+

0

25

Toro 47-2940

HP PIVOT ARM ASM

$51.99

$

Usually ships in 3-6 days

0

26

Toro 52-3620

Nut
(Superseded to 32153-11)

$4.49

$

In Stock, Qty 17

0

27

Toro 52-7480

L. HP SPRING ARM ASM

$

$

Not available

28

Toro 5-4460

WASHER-PIVOT

$7.99

$

In Stock, Qty 20+

0

29

Toro 3290-456

WASHER-BELLEVILLE

$2.99

$

In Stock, Qty 10

0

30

Toro 3296-29

NUT-LOCK, NI

$2.49

$

In Stock, Qty 20+

0

31

Toro 70-1620

Decal-53cm

$

$

Not available

32

Toro 52-7490

R HP SPRING ARM ASM

$

$

Not available

1

Toro 62-5440

Engine
(Superseded to 72-4144)

$

$

Not available

2

Toro 46-8290

TORO LOGO PLT
(Superseded to 98-3206)

$1.99

$

In Stock, only 3 left!

0

3

Toro 66-5370

SPRING-COMPRESSION

$11.99

$

Usually ships in 3-6 days

0

4

Toro 56-6190

Screw-Shoulder
(Superseded to 92-9698)

$5.49

$

In Stock, only 1 left!

0

5

Toro 66-5380

BRAKE PLATE ASM

$67.99

$

Usually ships in 3-6 days

0

6

Toro 46-0790

THO FORM SCREW M6 X 1

$

$

Not available

7

Toro 3290-459

RIVET-PLASTIC

$1.99

$

Usually ships in 3-6 days

0

8

Toro 60-9010

STRAP-GROUND

$11.99

$

Usually ships in 3-6 days

0

9

Toro 60-9020

Strap-Insulation
(Superseded to 77-5260)

$2.99

$

Usually ships in 3-6 days

0

10

Toro 53-4620

Plate-Mounting
(Superseded to 14-6009)

$

$

Not available

11

Toro 53-4610

CABLE CLAMP

$

$

Not available

12

Toro 53-4690

STOP-GROUND STRAP

$3.99

$

Usually ships in 3-6 days

0

13

Toro 12-5450

SCREW

$8.99

$

In Stock, only 2 left!

0

14

Toro 57-3120

DECAL-HV INT'L

$

$

Not available

15

Staple

$

$

Not available

16

Toro 81-3980

STOP

$7.49

$

In Stock, only 1 left!

0

17

Toro 56-6610

THRD FORMING SCREW

$4.99

$

Usually ships in 3-6 days

0

18

Toro 57-3830

TUBULAR SPACER

$4.99

$

Usually ships in 3-6 days

0

19

Toro 55-3570

GAS CAP ASM

$14.99

$

In Stock, Qty 20+

0

20

Toro 55-3530

TANK ASM

$137.99

$

In Stock, only 2 left!

0

21

Toro 2412-95

CLAMP-FUEL LINE

$1.49

$

In Stock, Qty 15

0

22

Toro 51-3211

LINE-GAS

$6.49

$

In Stock, Qty 7

0

23

Toro 56-6360

FILTER-FUEL

$6.99

$

In Stock, Qty 20+

0

24

Toro 51-3214

HOSE-FUEL

$5.49

$

In Stock, Qty 5

0

25

Toro 11-0590

SCREW-HWHTF
(Superseded to 32144-102)

$3.49

$

In Stock, Qty 5

0

26

Toro 62-7540

BLADE RETAINER

$83.99

$

In Stock, only 1 left!

0

27

Toro 42-1000

BLADE-21in
(Superseded to 107-4276-03)

$30.99

$

In Stock, Qty 7

0

28

Toro 3253-22

WASHER-LOCK

$2.99

$

In Stock, Qty 5

0

29

Toro 26-0670

SCREW-BLADE

$

$

Not available

Toro 56-6680

Drain Tube
(Superseded to 75-9850)

$

$

Not available

Toro 12-4599

Mounting Plate Assembly (Incl. Ref. #7-10)
(Superseded to 14-6009)

$

$

Not available
