20581 - Toro Walk-Behind Mower (SN: 008000001 - 008999999) (1988) BRAKE ASSEMBLY Parts Diagram

Walk-Behind Mower

BRAKE ASSEMBLY Parts Diagram

  • Title
1

Toro Part# 46-0790

THO FORM SCREW M6 X 1
Usually ships same day

Not available

$

$

2

Toro Part# 53-4620

Plate-Mounting
(Superseded to 14-6009)
Usually ships in 5 to 8 days

$

$28.97

0

3

Toro Part# 3290-459

RIVET-PLASTIC
Usually ships in 5 to 8 days

$

$1.61

0

4

Toro Part# 60-9020

Strap-Insulation
(Superseded to 77-5260)
Usually ships in 5 to 8 days

$

$2.04

0

5

Toro Part# 66-5380

BRAKE PLATE ASM
Usually ships in 5 to 8 days

$

$55.21

0

6

Toro Part# 56-6190

Screw-Shoulder
(Superseded to 92-9698)
Usually ships in 1 day

$

$4.45

0

7

Toro Part# 60-9010

STRAP-GROUND
Usually ships in 5 to 8 days

$

$9.76

0

8

Toro Part# 56-6092

BRAKE CABLE
Usually ships same day

Not available

$

$

9

Toro Part# 66-5370

SPRING-COMPRESSION
Usually ships in 5 to 8 days

$

$9.44

0

10

Toro Part# 53-4610

CABLE CLAMP
Usually ships same day

Not available

$

$

11

Toro Part# 53-4690

STOP-GROUND STRAP
Usually ships in 5 to 8 days

$

$3.11

0

Usually ships in 1 day

$

$7.03

0

Toro Part# 12-4599

Mounting Plate Assembly (Incl. Ref. #2-4, & 7)
(Superseded to 14-6009)
Usually ships in 5 to 8 days

$

$28.97

0
