55402 (960) - Toro Suburban Lawn Tractor (SN: 009000001 - 009999999) (1969) 42" MOWER DECK ASSEMBLY (CONT-D) Parts Diagram

Suburban Lawn Tractor

42" MOWER DECK ASSEMBLY (CONT-D) Parts Diagram

  • Title

1

Toro 7-0577

Spacer

$

$

Not available

2

Toro 7-0073

Belt
(Superseded to 28-8630)

$22.99

$

Usually ships in 3-6 days

0

3

Toro 7-0578

Pulley

$

$

Currently unavailable

4

32121-74S

Roll Pin

$

$

Not available

5

Toro 7-0638

Bearing Housing

$

$

Currently unavailable

6

Toro 7-0126

Washer

$

$

Not available

7

Toro 7-0634

Pulley

$

$

Not available

8

Toro 7-0633

BLADE DRIVE SHAFT

$

$

Not available

9

Toro 251-5

Bearing
(Superseded to 38-7820)

$13.99

$

In Stock, Qty 20+

0

10

Toro 7-0641

Bearing Housing

$

$

Not available

11

Toro 3257-23

KEY-WOODRUFF

$7.49

$

In Stock, only 2 left!

0

12

Toro 3246-5

Set Screw

$

$

Currently unavailable

13

Toro 7-0626

Spacer

$

$

Not available

14

Toro 3218-3

NUT-JAM

$0.99

$

In Stock, Qty 20+

0

15

Toro 7-0136

Pulley
(Superseded to 3-4244)

$27.99

$

In Stock, only 2 left!

0

16

32152-1S

Nut

$

$

Not available

17

Toro 7-3377

Idler Arm

$

$

Currently unavailable

18

Toro 7-0083

Bushing

$

$

Currently unavailable

19

Toro 3256-3

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

20

32152-1S

Nut

$

$

Not available

21

Toro 3256-3

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

22

Toro 322-3

SCREW-HH

$0.99

$

In Stock, Qty 20+

0

23

Toro 7-0630

V-BELT

$165.99

$

Usually ships in 3-6 days

0

24

Toro 321-2

SCREW-HH

$3.49

$

Usually ships in 3-6 days

0

25

Toro 7-0553

Washer

$

$

Currently unavailable

26

Toro 5-1077

KEY-SQUARE

$6.49

$

In Stock, only 2 left!

0

27

Toro 7-0627

Pulley

$

$

Currently unavailable

28

3242-13S

Set Screw

$

$

Not available

29

Toro 7-0131

Washer
(Superseded to 3256-27)

$2.99

$

In Stock, only 2 left!

0

30

32140-55S

Sems Screw

$

$

Not available

31

Toro 7-3370

Belt Guide

$

$

Currently unavailable

32

Toro 7-0636

Support

$

$

Currently unavailable

33

Toro 7-0276

Roller

$

$

Currently unavailable

34

Toro 3272-11

PIN-COTTER

$1.49

$

In Stock, Qty 10

0

35

Toro 7-0277

ROLLER SHAFT

$

$

Not available

36

Toro 7-0593

Bracket

$

$

Currently unavailable

37

Toro 32152-2S

Nut

$

$

Currently unavailable

38

241-87S

Wheel

$

$

Not available

39

Toro 7-0262

Axle

$

$

Currently unavailable

40

Toro 322-2

SCREW-HH

$2.49

$

In Stock, Qty 20+

0

41

Toro 7-0354

BELT

$

$

Not available

42

Toro 7-0131

Washer
(Superseded to 3256-27)

$2.99

$

In Stock, only 2 left!

0

43

Toro 7-0574

Housing

$

$

Not available

44

Toro 251-5

Bearing
(Superseded to 38-7820)

$13.99

$

In Stock, Qty 20+

0

45

Toro 7-0597

LH BLADE SHAFT

$

$

Not available

46

Toro 7-0287

MOWER SPINDLE HOUSING

$

$

Not available

47

Toro 322-4

SCREW-HH

$0.99

$

In Stock, Qty 20+

0

48

Toro 7-3590

WASHER

$2.99

$

In Stock, only 1 left!

0

49

Toro 7-0253

WASHER

$

$

Not available

50

Toro 7-0587

Blade

$

$

Currently unavailable

51

Toro 32152-6S

Nut

$

$

Currently unavailable

52

Toro 7-0252

Washer

$

$

Not available

53

Toro 322-3

SCREW-HH

$0.99

$

In Stock, Qty 20+

0

54

Toro 7-0582

IDLER ARM SPRING

$

$

Not available

55

32140-55S

Sems Screw

$

$

Not available

56

Toro 322-2

SCREW-HH

$2.49

$

In Stock, Qty 20+

0

57

Toro 322-6

SCREW-HH

$3.99

$

In Stock, Qty 20+

0

58

Toro 7-0581

Spacer

$

$

Currently unavailable

59

Toro 7-0598

Blade Shaft

$

$

Not available

60

Toro 7-0624

Roller

$

$

Not available

61

Toro 7-0590

ROLLER SHAFT

$

$

Not available

62

Toro 32152-4S

Nut

$

$

Currently unavailable

63

Toro 3229-11

SCREW-CARR

$1.49

$

In Stock, Qty 20+

0

64

Toro 7-0588

Guard

$

$

Not available

65

Toro 7-0573

Mulcher

$

$

Currently unavailable

67

Toro 7-0592

Bracket

$

$

Currently unavailable

68

Toro 2410-7

Plug Button

$

$

Currently unavailable
