61-20RG01 (D-250) - Toro Lawn Tractor (1977) GENERATOR Parts Diagram

Lawn Tractor

GENERATOR Parts Diagram

  • Title

1

Toro 250521

Generator

$

$

Not available

2

Toro 250706

Spacer

$

$

Not available

3

Toro 250707

Fan

$

$

Not available

4

Toro 250708

Pulley

$

$

Not available

5

Toro 250863

Nut

$

$

Not available

6

Toro 250864

Key

$

$

Not available

7

Toro 250709

Bearing

$

$

Not available

8

Toro 250865

Lock Washer

$

$

Not available

9

Toro 250710

Screw

$

$

Not available

10

Toro 250882

Nut

$

$

Not available

11

Toro 250711

Brush Set

$

$

Not available

12

Toro 250712

Lubricating Felt

$

$

Not available

13

Toro 250713

Clamp

$

$

Not available

14

Toro 250714

Earthing Clamp

$

$

Not available

15

Toro 250715

Commutator End Plate Assembly

$

$

Not available

16

Toro 250870

Lock Washer

$

$

Not available

17

Toro 250716

Screw

$

$

Not available

18

Toro 250717

Spring

$

$

Not available

19

Toro 250718

Brush Holder

$

$

Not available

20

Toro 250719

Armature

$

$

Not available

21

Toro 250720

Clamp

$

$

Not available

22

Toro 250721

Field Winding

$

$

Not available

23

Toro 250722

Screw

$

$

Not available
