896001 (SP-3000) - Gravely SnowEx Spreader (SN: 000101 & Above) Drive Assembly Parts Diagram

SnowEx Spreader

Drive Assembly Parts Diagram

  • Title

1

Gravely 21901615

HAIR PIN COTTER .093 X 2-3/8, ZINC

$

$

Not available

2

Gravely 21901616

NUT

$

$

Not available

3

Gravely 21901619

TRANSMISSION8:1, WORM GEAR

$

$

Not available

4

Gravely 21901620

COVERSPINNER DRIVE ENCLOSURE

$

$

Not available

5

Gravely 21901621

BOLT, 1/4-20 X 1/2 SERR FLANGE, STAINLESS (5PK)

$

$

Not available

6

Gravely 21901622

BOLT

$

$

Not available

7

Gravely 21901623

BOLT

$

$

Not available

8

Gravely 21901624

NUT

$

$

Not available

9

Gravely 21901627

POWER CABLE 26-1/2

$

$

Not available

10

Gravely 21901628

WASHER

$

$

Not available

11

Gravely 21901629

BOLT, #10-32 X 5/8 SERRATEDFLANGE, ZINC, W/PATCH (5PK)

$

$

Not available

12

Gravely 21901631

MOTOR 3.0 X 3.8 12 VOLT DC

$

$

Not available

13

Gravely 21901632

MOTOR DRIVE COUPLER

$

$

Not available

14

Gravely 21901636

CE SHROUD

$

$

Not available

15

Gravely 21901637

BOLT

$

$

Not available

16

Gravely 21901638

RETAINER, 1/4 X 3/4 X 1/2 6 PK

$

$

Not available

17

Gravely 21901654

SPINNER W/ EXTENDED SHAFT, 12

$

$

Not available

18

Gravely 21901655

MATERIAL CHUTE PRO TRUCK

$

$

Not available

19

Gravely 21901656

BOLT

$

$

Not available

20

Gravely 21901664

SPINNER DRIVE ENCLOSURE

$

$

Not available

21

Gravely 21901665

TUBULAR SPINNER GUARD PRO TRUCK

$

$

Not available

22

Gravely 21901672

BENT PIN 1/2 X 20

$

$

Not available

23

Gravely 21901673

SPINNER DEFLECTOR PRO TRUCK

$

$

Not available

24

Gravely 21901675

DRIVE ENCLOSURE SHROUD

$

$

Not available

25

Gravely 21901679

NUT

$

$

Not available

26

Gravely 21901683

NUT, 5/16-18 BLACK NYLON2PK

$

$

Not available
