990894 - Simplicity 30" Mower Deck Electrical Group Parts Diagram

30" Mower Deck

Electrical Group Parts Diagram

  • Title

1

Simplicity 2122216SM

SOLENOID

$

$

Not available

2

Simplicity 177984

WIRE ASSY. (PTO switch to solenoid)

$

$

Not available

3

Simplicity 178444

WIRE

$

$

Not available

4

Simplicity 177985

WIRE ASSY. (Switch to ignition switch)

$

$

Not available

5

Simplicity 177982

CABLE ASSY., Solenoid (To starter)

$

$

Not available

6

Simplicity 176623

SUPPORT ASSY. (Battery)

$

$

Not available

7

Simplicity 176912

CLIP, Wire

$

$

Not available

8

Simplicity 177390

BATTERY & CLIP ASSY.

$

$

Not available

9

Simplicity 920299

NUT, Speed

$

$

Not available

10

Simplicity 2828688

SCREW, Self Tapping, #10 x 1/2

$

$

Not available

11

Simplicity 2176975

CABLE ASSY. (Battery neg. to ground)

$

$

Not available

12

Simplicity 177981

CABLE ASSY. (Battery to solenoid)

$

$

Not available

13

Simplicity 2832771

CLIP, Cable

$

$

Not available

14

Simplicity 178171

RESISTOR

$

$

Not available

15

Simplicity 172410

FUSE, 7-1/2 Amp

$

$

Not available

16

Simplicity 178172

WIRE ASSY.

$

$

Not available

17

Simplicity 178173

WIRE ASSY.

$

$

Not available

18

Simplicity 177983

WIRE ASSY., Ignition (Switch to Solenoid)

$

$

Not available
