HCS 13 F (965869401) - Husqvarna Collection System (2008-07) Hitch Assembly Parts Diagram

Collection System

Hitch Assembly Parts Diagram

  • Title

1

Husqvarna 539111155

HITCH

$424.99

$

Usually ships in 3-10 days

0

2

Husqvarna 539111190

LATCH

$66.99

$

Usually ships in 3-10 days

0

3

Husqvarna 539977250

SPRING

$

$

Not available

4

Husqvarna 539111157

MOUNT Z BRACE

$141.99

$

Usually ships in 3-10 days

0

5

Husqvarna 539111167

SEAL RUBBER

$27.99

$

Usually ships in 3-10 days

0

6

Husqvarna 539111158

SUPPORT, OUTER

$

$

Not available

7

Husqvarna 539111162

SUPPORT ARM

$157.99

$

Usually ships in 3-10 days

0

8

Husqvarna 539111267

BRACKET, SUPPORT

$11.99

$

Usually ships in 3-10 days

0

9

Husqvarna 539111171

SEAL STRAP

$27.99

$

Usually ships in 3-10 days

0

10

Husqvarna 539990580

HCS ¼-20 x ¾

$3.99

$

In Stock, only 4 left!

0

11

Husqvarna 539990563

HCS 3/8-16 x 1

$1.49

$

Usually ships in 3-10 days

0

12

Husqvarna 539990655

HCS 3/8-16 x 1½

$4.99

$

In Stock, only 2 left!

0

13

Husqvarna 539108369

HCS ½-13 x 1¼

$3.99

$

Usually ships in 3-10 days

0

14

Husqvarna 539976978

NUT ¼-20 NYLOC
(Superseded to 595086601)

$3.99

$

Usually ships in 3-10 days

0

15

Husqvarna 539976979

NUT 3/8-16 NYLOC
(Superseded to 596240901)

$3.99

$

In Stock, Qty 20+

0

16

Husqvarna 539990254

WASHER ½

$3.99

$

Usually ships in 3-10 days

0

17

Husqvarna 539990613

NUT 3/8-16 WHIZLK

$3.99

$

Usually ships in 3-10 days

0

18

Husqvarna 539101331

NUT ½-13 NYLOC
(Superseded to 596135601)

$3.99

$

In Stock, Qty 20+

0

19

Husqvarna 539990625

NUT ½ JAM

$3.99

$

In Stock, Qty 15

0

20

Husqvarna 539111187

NUT ½-13 WHIZLOCK

$3.99

$

Usually ships in 3-10 days

0
