Kohler Parts Lookup & Diagrams

Need help finding your Kohler model number?

Your Kohler equipment has a factory model number and serial number on a sticker-like label or metallic tag attached to the unit in a place away from moving parts (usually near the handle, under the seat, or on the side of the unit). The best way to buy repair parts for your Kohler is to begin by searching for your Kohler model number on PartsTree and use the OEM Kohler parts diagrams to find the parts that fit exactly like the originals from the Kohler factory. When you locate your Kohler model tag, take a picture for future repair parts needs.

What do Kohler model tags look like?

examples of what Kohler model tags usually look like and a large Kohler logo
A Note On Engine Parts

To buy engine parts for your Kohler, like an air filter, oil filter, fuel filter, spark plug, tune-up kit, or carburetor parts, you will likely need to search separately on PartsTree for your engine model. On Kohler equipment, the engine model and specification ("spec") numbers, as well as serial number and sometimes type and code, are often stamped above the muffler, by the spark plug, or near the overhead valve cover.
