0053480 - Generac Portable Generator (SN: 4995868 - 8281183) (2016) Control Panel (0G5711-B) Parts Diagram

Portable Generator

Control Panel (0G5711-B) Parts Diagram

  • Title

1

Generac 058000H

NUT TRIC M3 X .5

$1.49

$

Usually ships in 2-12 days

0

2

Generac 092036

SCREW PPHM #6-32 X 1/4 SEMS

$

$

Not available

3

0G2357

CONTROL PANEL 8KW ENCL PORTABLE

$

$

Not available

4

Generac 0G6131

SCREW HHC M6-1.0 X 30 C8.8 FT

$1.49

$

Usually ships in 2-12 days

0

5

Generac 022473

WASHER FLAT 1/4-M6 ZINC
(Superseded to G022473)

$2.99

$

Usually ships in 2-12 days

0

6

Generac 0G5813

ASSEMBLY PCB PORTABLE SYSTEM CONTROL

$61.99

$

Usually ships in 2-12 days

0

7

Generac 0D3062

HEX STAND-OFF #6-32 X 3/8"

$3.99

$

Usually ships in 2-12 days

0

8

Generac 0A1658

WASHER LOCK SPECIAL 1/4"

$17.99

$

Usually ships in 2-12 days

0

9

Generac 049813

NUT HEX M6 X 1.0 G8 YEL CHR
(Superseded to G049813)

$3.49

$

Usually ships in 2-12 days

0

10

Generac 0C1085

SCREW PPHM M3-0.5 X 8

$0.99

$

Usually ships in 2-12 days

0

11

Generac 043182

WASHER LOCK M3
(Superseded to G043182)

$0.99

$

Usually ships in 2-12 days

0

12

Generac 0D4804

TRANSFORMER, IDLE CURRENT PORTABLE

$17.99

$

Usually ships in 2-12 days

0

13

0G4759

GASKET PORTABLE CONTROL PANEL

$

$

Not available

14

Generac 0G5644

CIRCUIT BREAKER, 2-P 35A W/SHUNT TRIP (AIRPAX PART NUMBER: LEL12-1REC5-36494-35-G1-V)

$247.99

$

Usually ships in 2-12 days

0

15

Generac 0D4968

OUTLET 20A 120V DPLX

$38.99

$

In Stock, only 1 left!

0

16

Generac 075207

CIRCT BRK 20X1 UL/CSA
(Superseded to G075207)

$12.99

$

Usually ships in 2-12 days

0

17

Generac 087968

SWITCH, MOMENTARY (OFF) - ON
(Superseded to G087968)

$2.49

$

Usually ships in 2-12 days

0

18

Generac 0G5699

12VDC POWER JACK

$33.99

$

Usually ships in 2-12 days

0

19

Generac 0G5602

CIRCUIT BREAKER 30A 2P PUSH TO RESET (AIRPAX PART NUMBER: PR21-2-30.OA-XX)

$87.99

$

Usually ships in 2-12 days

0

20

Generac 068868

OUTLET 30A 120V RECEPT
(Superseded to G068868)

$46.99

$

In Stock, only 2 left!

0

21

Generac 075207A

CIRCT BRK 30X1 UL/CSA

$13.99

$

In Stock, only 2 left!

0

22

Generac 043437

RECEPTACLE 30A 125/250V L1430R
(Superseded to G043437)

$21.99

$

In Stock, only 1 left!

0

23

Generac 043180

WASHER, FLAT, M4

$

$

Not available

24

Generac 022264

WASHER LOCK #8-M4
(Superseded to G022264)

$0.99

$

Usually ships in 2-12 days

0

25

Generac 051715

NUT HEX M4-0.7 G8 YEL CHR
(Superseded to G051715)

$9.49

$

Usually ships in 2-12 days

0

26

0G5922

SCREW PPHM #6-32 X 1/4 SEMS, BLACK OXIDE W/OIL

$

$

Not available

27

0G2361

410 CONTROL PANEL COVER

$

$

Not available

28

0G5692

WIRE HARNESS (NOT SHOWN)

$

$

Not available

29

Generac 074908

SCREW HHTT M5-0.8 x 1.0
(Superseded to G074908)

$1.99

$

In Stock, Qty 6

0

30

Generac 0G6017

GFCI SENSING MODULE ASSEMBLY

$162.99

$

Usually ships in 2-12 days

0

31

Generac 0G5726

GASKET GFCI

$

$

Currently unavailable

32

Generac 086729

CONTACTOR, STARTER SOLENOID
(Superseded to G086729)

Note: IF HARDWARE IS NEEDED ORDER (2) 022471 NUT, (2) 022127 NUT,(2) 022264 LOCKWASHER, AND(2) 022097 LOCKWASHER

$48.99

$

In Stock, only 1 left!

0

33

Generac 0D5303

WASHER FLAT 0.25ID X 1"OD ZINC

Note: ORDER 071693 IT IS THE SAME AS 0D5303

$0.99

$

In Stock, only 1 left!

0

34

Generac 022097

WASHER LOCK M6-1/4
(Superseded to G022097)

$3.99

$

Usually ships in 2-12 days

0

35

Generac 043116

SCREW HHC M6-1.0 X 12 G8.8
(Superseded to G043116)

$0.99

$

Usually ships in 2-12 days

0

36

0742600175

WIRE, #16 START SOL-STARTER

$

$

Not available

37

0G5875

WIRE HARNESS BACK CONTROL PANEL CONTROL (NOT SHOWN)

$

$

Not available

38

0G5876

WIRE HARNESS BACK CONTROL PANEL POWER (NOT SHOWN)

$

$

Not available

39

Generac 0F5458

SCREW PLASTITE HI-LOW #10 X 3/8

$0.99

$

Usually ships in 2-12 days

0

40

Generac 022127

NUT HEX 1/4-20 STEEL
(Superseded to G022127)

$5.49

$

Usually ships in 2-12 days

0

41

Generac 0G6392

BOOT, BATTERY CABLE

$0.99

$

Usually ships in 2-12 days

0

42

0742600176

WIRE, STARTER SOL-BATTERY

$

$

Not available

43

Generac 0912970098

WIRE, JUMPER GFCI

$

$

Not available

44

Generac 092120

NUT, TRIC M6-1.0

$

$

Not available
