020270-0 - Briggs & Stratton 3,000 PSI Pressure Washer Main Unit Parts Diagram

3,000 PSI Pressure Washer

Main Unit Parts Diagram

  • Title

1

Briggs & Stratton 196438GS

BASE, w/Mounts

$204.99

$

Usually ships in 2-12 days

0

2

Briggs & Stratton S195428GS

HANDLE

$94.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton 199410GS

KIT, Billboard Assy, w/Clips

$58.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton 195964GS

Clips, Tree

$4.99

$

Usually ships in 2-12 days

0

Briggs & Stratton 30809GS

Grommet

$4.49

$

Usually ships in 2-12 days

0

4

Briggs & Stratton 196439GS

KIT, Wheel

$75.99

$

In Stock, Qty 5

0

Briggs & Stratton 192050GS

E-Ring
(Superseded to 703976)

$4.49

$

In Stock, Qty 20+

0

Briggs & Stratton 195454GS

Axle

$12.99

$

Usually ships in 2-12 days

0

5

Briggs & Stratton 198164GS

ASSY, Pump
(Superseded to 206376GS)

$385.99

$

Usually ships in 2-12 days

0

6

Briggs & Stratton B2384GS

Filter, Inlet

$4.49

$

In Stock, only 3 left!

0

7

Briggs & Stratton 190593GS

Kit, Chemical Injection

$

$

Not available

8

Briggs & Stratton 190589GS

Kit, Outlet

$41.99

$

In Stock, only 1 left!

0

9

Briggs & Stratton 190588GS

Kit, Water Inlet

$69.99

$

Usually ships in 2-12 days

0

10

Briggs & Stratton 194298GS

Valve, Thermal Relief
(Superseded to 208673GS)

$14.99

$

In Stock, Qty 13

0

11

Briggs & Stratton 23139DGS

Key

$4.49

$

Usually ships in 2-12 days

0

12

Briggs & Stratton 196006GS

HOSE
(Superseded to 84006753)

$59.99

$

In Stock, Qty 20+

0

13

Briggs & Stratton B2203GS

KIT, Handle Connector

$5.49

$

In Stock, only 2 left!

0

14

Briggs & Stratton 75246GS

HHS, Trilobular, 3/8-16 x 1 1/4

$3.99

$

Usually ships in 2-12 days

0

15

Briggs & Stratton 199117GS

GUN
(Superseded to 704312)

$93.99

$

In Stock, only 1 left!

0

16

Briggs & Stratton 200595GS

WAND
(Superseded to 706595)

$47.99

$

In Stock, Qty 9

0

17

Briggs & Stratton 192131GS

KIT, Pump Mounting Hardware

$5.99

$

Usually ships in 2-12 days

0

18

Briggs & Stratton 192310GS

KIT, Vibration Mount

Note: (see "Pump")

$9.99

$

In Stock, only 4 left!

0

19

Briggs & Stratton 195889GS

KIT, Nozzles
(Superseded to 202182GS)

$31.99

$

Usually ships in 2-12 days

0

19

Briggs & Stratton 198841GS

Nozzle, Plastic, Soap

$10.99

$

Usually ships in 2-12 days

0

19

Briggs & Stratton 195842AAGS

Nozzle, Project Pro, Red
(Superseded to 201580AAGS)

$10.99

$

Usually ships in 2-12 days

0

19

Briggs & Stratton 201580XGS

Nozzle, Project Pro, Orange
(Superseded to 195983XGS)

$10.99

$

In Stock, Qty 5

0

19

Briggs & Stratton 195842RGS

Nozzle, Project Pro, Yellow
(Superseded to 201580RGS)

$11.99

$

Usually ships in 2-12 days

0

900

§

ENGINE

Note: Contact Engine Manufacturer

$

$

Not available

900

Briggs & Stratton 199262GS

MANUAL, Operator's

Note: Not Illustrated

$14.99

$

Usually ships in 2-12 days

0

900

Briggs & Stratton MS5532

MANUAL, Engine

Note: Not Illustrated

$

$

Not available

900

Briggs & Stratton 194256GS

KIT, Tag/Warning Service
(Superseded to 705752)

Note: Not Illustrated

$3.99

$

Usually ships in 2-12 days

0

900

Briggs & Stratton BB3061BGS

OIL BOTTLE
(Superseded to 100005)

Note: Not Illustrated

$8.99

$

In Stock, Qty 8

0

900

Briggs & Stratton 87815GS

GOGGLES

Note: Not Illustrated

$12.99

$

Usually ships in 2-12 days

0

900

Briggs & Stratton 6048

KIT, O-Ring
(Superseded to 705001)

Note: Optional Accessories

$18.99

$

In Stock, Qty 8

0

900

Briggs & Stratton 6039

PUMP SAVER

Note: Optional Accessories

$12.99

$

In Stock, only 2 left!

0
