020291-1 - Brute 2,500 PSI Pressure Washer Main Unit Parts Diagram

2,500 PSI Pressure Washer

Main Unit Parts Diagram

  • Title

1

Briggs & Stratton 201769GS

BASE ASSEMBLY

$

$

Not available

2

Briggs & Stratton B201594GS

HANDLE

$75.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton 201828GS

CHEMICAL TANK ASSEMBLy, With Clips

$41.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton 195964GS

CLIP

$4.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton 192980GS

KIT, Valve

$17.99

$

In Stock, Qty 20+

0

4

Briggs & Stratton 196006GS

HOSE
(Superseded to 84006753)

$59.99

$

In Stock, Qty 20+

0

5

Briggs & Stratton 95597GS

BRUSH, Broom
(Superseded to 100510GS)

$85.99

$

Usually ships in 2-12 days

0

6

Briggs & Stratton 194264GS

KIT, Hook, Handle

$5.49

$

In Stock, only 1 left!

0

7

Briggs & Stratton 192529GS

KIT, Pump Mounting Hardware

$6.99

$

Usually ships in 2-12 days

0

8

Briggs & Stratton 88935GS

ADAPTER, Brush
(Superseded to B1051GS)

$11.99

$

Usually ships in 2-12 days

0

9

Briggs & Stratton B3222EGS

CAP, Chem Container

$5.49

$

Usually ships in 2-12 days

0

10

Briggs & Stratton 202605GS

PUMP

$328.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton 23139GS

KEY

$4.49

$

Usually ships in 2-12 days

0

--

Briggs & Stratton 194298GS

VALVE, Thermal Relief
(Superseded to 208673GS)

$14.99

$

In Stock, Qty 13

0

11

Briggs & Stratton 192309GS

KIT, Hook, Base

$4.49

$

Usually ships in 2-12 days

0

12

Briggs & Stratton 196439GS

KIT, Wheel

$75.99

$

In Stock, Qty 5

0

--

Briggs & Stratton 192050GS

E-Ring
(Superseded to 703976)

$4.49

$

In Stock, Qty 20+

0

--

Briggs & Stratton 195454GS

AXLE

$12.99

$

Usually ships in 2-12 days

0

13

Briggs & Stratton B2203GS

KIT, Handle Connector

$5.49

$

In Stock, only 3 left!

0

14

Briggs & Stratton 88934GS

EXTENSION

$54.99

$

Usually ships in 2-12 days

0

15

Briggs & Stratton 193482GS

GUN
(Superseded to 708807)

$74.99

$

Usually ships in 2-12 days

0

16

Briggs & Stratton 192310GS

KIT, Vibration Mount

$9.99

$

In Stock, Qty 5

0

17

Briggs & Stratton 88185GS

BRUSH, Utility

$77.99

$

Usually ships in 2-12 days

0

18

Briggs & Stratton 198974GS

WAND ASSEMBLY, Adjust
(Superseded to 205015CGS)

$67.99

$

In Stock, only 4 left!

0

19

Briggs & Stratton B1236CGS

ORIFICE

$14.99

$

Usually ships in 2-12 days

0

20

Briggs & Stratton 95598GS

HANDLE, Brush

$24.99

$

Usually ships in 2-12 days

0

900

-----

* ENGINE

$

$

Not available

--

Briggs & Stratton 203775GS

MANUAL,Operator's

Note: (Not Illustrated)

$14.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton BB3061BGS

OIL BOTTLE
(Superseded to 100005)

Note: (Not Illustrated)

$8.99

$

In Stock, Qty 8

0

--

Briggs & Stratton 87815GS

GOGGLES

Note: (Not Illustrated)

$12.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton A1040NGS

HOSE, Chemical

Note: (Not Illustrated)

$12.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton 282398

COVER

Note: (Not Illustrated)

$

$

Currently unavailable

--

Briggs & Stratton 201628GS

DECAL, Eng Shroud

Note: (Not Illustrated)

$11.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton 275171

LABEL, B&S Logo

Note: (Not Illustrated)

$

$

Currently unavailable

--

Briggs & Stratton 194256GS

KIT, Tag Warning
(Superseded to 705752)

Note: (Not Illustrated)

$3.99

$

Usually ships in 2-12 days

0

--

Briggs & Stratton 6048

KIT, O-Ring
(Superseded to 705001)

Note: (Optional Accessory)

$18.99

$

In Stock, only 3 left!

0

--

Briggs & Stratton 6039

PUMP SAVER

Note: (Optional Accessory)

$12.99

$

In Stock, only 2 left!

0
