02712 - Toro 48" Rear-Discharge Mower Deck (SN: 410000000 - 999999999) Caster Assembly Parts Diagram

48" Rear-Discharge Mower Deck

Caster Assembly Parts Diagram

  • Title

1

Toro 110-5023

WHEEL AND TIRE ASM

$101.99

$

In Stock, Qty 7

0

1:1

TIRE

Note: Not serviced separately

$

$

Not available

1:2

Toro 1-513809

BEARING

$37.99

$

In Stock, Qty 20+

0

1:3

Toro 1-513810

BUSHING

$6.49

$

In Stock, Qty 20+

0

1:4

Toro 302-61

FITTING-GREASE

$12.99

$

In Stock, Qty 6

0

1:5

WHEEL

Note: Not serviced separately

$

$

Not available

2

Toro 1-513547

SPACER

$13.99

$

In Stock, Qty 12

0

3

Toro 325-20

SCREW-HH

$8.49

$

In Stock, Qty 20+

0

4

Toro 116-7942-01

FORK-CASTER

$101.99

$

Usually ships in 3-6 days

0

5

Toro 3217-9

NUT-HH

$0.99

$

In Stock, Qty 20+

0

6

Toro 3253-7

WASHER-LOCK

$1.49

$

In Stock, Qty 20+

0

7

Toro 1-303314

SPACER-CASTER

$6.99

$

In Stock, Qty 20+

0

8

Toro 110-2130

SUPPORT ASM

$303.99

$

Usually ships in 3-6 days

0

8:2

Toro 1-303514

BEARING-FLANGED

$13.99

$

In Stock, Qty 20+

0

8:3

Toro 302-52

FITTING-GREASE

$6.99

$

In Stock, Qty 20+

0

9

Toro 1-513338

WASHER-FLAT

$4.49

$

In Stock, Qty 20+

0

10

Toro 1-809020

PIN

$12.99

$

In Stock, Qty 5

0

11

Toro 3290-357

NUT-HHF, WHIZ

$0.99

$

In Stock, Qty 20+

0

12

Toro ZWQ1J000U

WASHER-PLAIN

$

$

Currently unavailable

13

Toro 323-7

SCREW-HH

$3.49

$

In Stock, Qty 20+

0

14

Toro 111-1900-01

SPACER-CASTER

$

$

Currently unavailable
