118-072C190 - White Outdoor Lawn Boss 20" Walk-Behind Mower (1988) Rotary Mower Parts Diagram

Lawn Boss 20" Walk-Behind Mower

Rotary Mower Parts Diagram

  • Title

1

White Outdoor 731-0794

Rear Flap Assemblv

$

$

Not available

2

White Outdoor 14836

Retainer Strip

$

$

Not available

3

White Outdoor 710-0776

Hex AB-Tap Scr. 1/4" x .62" Lg.
(Superseded to 710-0896)

$3.99

$

In Stock, Qty 20+

0

4

White Outdoor 12935

Handle Mount Brkt.-L.H.

$

$

Not available

White Outdoor 12936

Handle Mount Brkt.-R.H.

Note: (Not Shown)

$

$

Not available

5

White Outdoor 731-0564

Plastic Plug

$

$

Not available

6

White Outdoor 710-0603

Hex Sen-Tap Scr. 5/16-18 x .5" Lg.

$4.49

$

Usually ships in 3-6 days

0

7

White Outdoor 14995

20" Deck Ass'y.

Variations

White Outdoor 14995-0483

No Longer Available DECK ASSEMBLY-20IN - CHARCOAL GRAY (0483)

$

$

Not available

White Outdoor 14995-0629

No Longer Available - SILVER FLAKE (0629)

$

$

Not available

White Outdoor 14995-0638

No Longer Available DECK ASSEMBLY-20IN - MTD/TROY-BILT RED (0638)

$

$

Not available

White Outdoor 14995-0662

No Longer Available DECK ASSEMBLY-20IN - OYSTER GRAY (0662)

$

$

Not available

$

$
