1319 PS (1691098) - Simplicity Walk-Behind Mower REPAIR PARTS LIST FOR MODEL 1319PS-19" Mower Parts Diagram

Walk-Behind Mower

REPAIR PARTS LIST FOR MODEL 1319PS-19" Mower Parts Diagram

  • Title

1

Simplicity 1677778

Deck

$

$

Not available

2

Simplicity 1677780

Extension-Discharge Chute

$

$

Not available

3

Simplicity 1677781

Guard-Blade

$

$

Not available

4

Simplicity 1664040SM

Blade-19"

$87.99

$

Usually ships in 2-12 days

0

5

Simplicity 1677784

Wheel 7 x 1.50

$

$

Not available

6

Simplicity 1677786

Cable-Engine/Blade Control

$

$

Not available

7

Simplicity 1700808

Control-Throttle, with cable

$

$

Not available

8

Simplicity 1677790

Handle-Lower

$

$

Not available

9

Simplicity 1677791

Handle-Upper

$

$

Not available

10

Simplicity 1677792

Washer-Blade

$

$

Not available

11

Simplicity 1677793

Clip-Trailing Shield

$

$

Not available

12

Simplicity 1677794

Bracket-Handle RH

$

$

Not available

13

Simplicity 1677795

Bracket-Handle LH

$

$

Not available

14

Simplicity 1677798

Bail-Engine/Blade Control

$

$

Not available

15

Simplicity 1677801

Cap-Hub

$

$

Not available

16

Simplicity 1701011SM

Cable Tie

$5.49

$

In Stock, only 2 left!

0

17

Simplicity 1677802

Tip-Adjuster Lever

$

$

Not available

18

Simplicity 1677803

Shield-Trailing

$

$

Not available

19

Simplicity 1664060

Adapter-Blade

$

$

Not available

20

Simplicity 1677959

Decal-Danger, Discharge Chute

$

$

Not available

21

Simplicity 1722551SM

Decal-Simplicity

$11.99

$

In Stock, only 2 left!

0

22

Simplicity 1700809

Decal-Blade Warning

$

$

Not available

23

Simplicity 1677962

Decal-3.5HP

$

$

Not available

24

Simplicity 1668701

Bolt-Wheel

$

$

Not available

25

Simplicity 1717312SM

Washer-Curved 5/16

$

$

Not available

26

Simplicity 2810224SM

Key-Woodruff #6

$3.99

$

Usually ships in 2-12 days

0

27

Simplicity 1677808

Clamp-Throttle Cable

$

$

Not available

28

Simplicity 1677805

Screw-Self Tap #10 x 5/8

$

$

Not available

29

Simplicity 1654998

Screw-Hex #10-32 x 3/8

$

$

Not available

30

Simplicity 1677804

Bolt-Curved Head 5/16-18 x 2 1/4

$

$

Not available

31

Simplicity 1677809

Stop-Rope

$

$

Not available

32

Simplicity 1677810

Bolt-Blade w/Lockwasher

$

$

Not available

33

Simplicity 1677811

Eyebolt-Rope Guide

$

$

Not available

34

Simplicity 1923358SM

Nut-Hex, 1/4-20 Lock
(Superseded to 703954)

$4.99

$

In Stock, Qty 20+

0

35

Simplicity 1664066

Bolt-Shoulder 3/8-16

$

$

Not available

36

Simplicity 1677813

Plate-Height Adjuster RH Rear, LH Front

$

$

Not available

37

Simplicity 1677814

Plate-Height Adjuster LH Rear, RH Front

$

$

Not available

38

Simplicity 1960253

Bolt-Carriage #10-24 x 1/2

$

$

Not available

39

Simplicity 1664067

Nut-Hex #10-24 Keps

$

$

Not available

40

Simplicity 1933896SM

Nut-Hex #10-24 Nylok
(Superseded to 703412)

$4.49

$

In Stock, Qty 12

0

41

Simplicity 1927187SM

Bolt-Self Tap 3/8-16 x 7/8

$4.49

$

In Stock, only 4 left!

0

42

Simplicity 1925003SM

Bolt-Self Tap 1/4-20 x 1/2
(Superseded to 704130)

$3.99

$

In Stock, Qty 20+

0

43

Simplicity 1933737SM

Bolt-Hex #10-24 x 1/2

$3.49

$

In Stock, only 2 left!

0

44

Simplicity 1923300SM

Washer-Shakeproof 5/16

$3.99

$

In Stock, only 4 left!

0

45

Simplicity 1921319SM

Washer-Fiat 1/4
(Superseded to 703332)

$4.49

$

In Stock, Qty 17

0

46

Simplicity 1664071

Baffle-Deck

$

$

Not available

47

Simplicity 1960074SM

Cotter-Hairpin
(Superseded to 703300)

$3.99

$

In Stock, Qty 20+

0

48

Simplicity 2828372SM

Nut-Hex 1/4-20 Keps
(Superseded to 703914)

$3.49

$

In Stock, Qty 18

0

49

Simplicity 1930645SM

Nut-Hex 3/8-16 Lock
(Superseded to 703893)

$6.99

$

In Stock, Qty 20+

0

50

Simplicity 1677816

Washer-Belleville

$

$

Not available

51

Simplicity 1677817

Knob-Handle Retaining

$

$

Not available

52

Simplicity 1677963

Decal-Starting Instructions

$

$

Not available

53

Simplicity 1960241SM

Rivet-Pop 1/4 Steel

$5.49

$

Usually ships in 2-12 days

0

54

Simplicity 1923341SM

Bolt-Hex 1/4-20 x 3/4

$4.49

$

In Stock, Qty 8

0

55

Simplicity 1664080

Lever-Height Adjustment

$

$

Not available

56

Simplicity 1664081

Arm-Wheel

$

$

Not available

57

Simplicity 1678060

Boot-Spark Plug

$

$

Not available

58

Simplicity 1677873

Cap-Plastic, Bolt End

$

$

Not available

59

Simplicity 1678147

Decal-Warning, Chute Deflector in Place

$

$

Not available

60

DECAL, OPEI

$

$

Not available

61

DECAL, Model Number

$

$

Not available
