132-690G000 - MTD Lawn Tractor (1992) Exhaust Pipe Assembly Parts Diagram

Lawn Tractor

Exhaust Pipe Assembly Parts Diagram

  • Title
1

MTD Part# 710-3209

Hex Bolt M6-1" x 10 MM Lg. (Gr. 5)
Usually ships in 5 to 10 days

$

$5.86

0

2

MTD Part# 710-0148

Hex Wash. Hd. F-Tap Scr. #8-32 x .38" Lg.
Usually ships in 1 day

$

$3.09

0

3

MTD Part# 651-0002

Exhaust Pipe Ass'y.
Usually ships same day

Not available

$

$

4

MTD Part# 710-0654A

Hex L-Wash. Tl-Tap Scr.3/8-16 x 1" Lg.
Usually ships in 1 day

$

$3.00

0

5

MTD Part# 17846

Muffler Heat Shield Ass'y.
Usually ships same day

Currently unavailable

$

$

6

MTD Part# 710-3140

Hex Cap Scr. M6-1" x 14 MM Lg.
Usually ships same day

Not available

$

$

7

MTD Part# 736-0270

Bell-Wash..265" I.D. x .75" O.D.
Usually ships in 5 to 10 days

$

$2.87

0

8

Part#

Muffler - Supplied by Engine Manufacturer
Usually ships same day

Not available

$

$

MTD Part# 726-0197

Cable Tie

Note: (Not Shown)

Usually ships in 1 day

$

$2.58

0
