1340 PW - Husqvarna Pressure Washer (2008-02) HYDRAULIC PUMP - MOTOR Parts Diagram

Pressure Washer

HYDRAULIC PUMP - MOTOR Parts Diagram

  • Title

505 19 45-62

Husqvarna 505194562

SCREW, HHC SEMS (M6X16)

$

$

Not available

505 19 45-66

Husqvarna 505194566

SCREW, HSH (M8X65)

$

$

Not available

531 30 75-92

Husqvarna 531307592

O-RING KIT

$

$

Not available

505 19 45-77

Husqvarna 505194577

SCREW, FLOW-THRU

$

$

Not available

505 19 45-62

Husqvarna 505194562

SCREW, HHC SEMS (M6X16)

$

$

Not available

505 19 45-68

Husqvarna 505194568

KIT, VALVE

$

$

Not available

531 30 75-22

Husqvarna 531307522

PLUG, VALVE WITH O-RING

$

$

Not available

505 27 18-04

Husqvarna 505271804

PUMP, CAT 66DX35 - PW1340
(Superseded to 583903301)

$

$

Not available

505 19 45-78

Husqvarna 505194578

UNLOADER REPAIR KIT

$

$

Not available

531 30 75-64

Husqvarna 531307564

OIL PLUG KIT

$

$

Not available

505 19 45-71

Husqvarna 505194571

CAP. ADJUSTING

$

$

Not available

505 19 45-75

Husqvarna 505194575

RETAINER, PISTON

$

$

Not available

531 30 75-23

Husqvarna 531307523

HEAD MANIFOLD

$

$

Not available

531 30 75-60

Husqvarna 531307560

SEAL KIT # 2, 66DX

$

$

Not available

505 19 45-70

Husqvarna 505194570

HANDLE, ADJUSTING

$

$

Not available

531 30 75-25

Husqvarna 531307525

LOCK WASHER, CONICAL (M8)

$

$

Not available

505 19 45-65

Husqvarna 505194565

CRANKSHAFT FOR 35GSI

$

$

Not available

505 19 45-76

Husqvarna 505194576

SCREW, FLOW-THRU

$

$

Not available

505 19 45-74

Husqvarna 505194574

SPRING

$

$

Not available

505 19 45-73

Husqvarna 505194573

SET SCREW

$

$

Not available

505 19 45-67

Husqvarna 505194567

KIT,SEAL

$

$

Not available

531 30 74-83

Husqvarna 531307483

PUMP OIL - SINGLE BOTTLE

$

$

Not available

531 30 75-20

Husqvarna 531307520

PIN, CROSSHEAD

$

$

Not available

505 19 45-79

Husqvarna 505194579

BEARING KIT

$

$

Not available

505 19 45-72

Husqvarna 505194572

NUT, LOCKING

$

$

Not available

505 19 45-69

Husqvarna 505194569

UNLOADER ASSY W/INJECTOR

$

$

Not available

531 30 75-26

Husqvarna 531307526

SCREW, FH (M8X25)

$

$

Not available

531 30 75-24

Husqvarna 531307524

FLANGE MOUNT

$

$

Not available

531 30 75-27

Husqvarna 531307527

ASSY, BOLT MOUNT

$

$

Not available

505 19 45-63

Husqvarna 505194563

COVER,BEARING

$

$

Not available

505 19 45-64

Husqvarna 505194564

ROD, CONNECTING

$

$

Not available

531 30 75-21

Husqvarna 531307521

ROD, PLUNGER

$

$

Not available

505 19 45-80

Husqvarna 505194580

INJECTOR KIT

$

$

Not available

531 30 75-62

Husqvarna 531307562

PLUNGER GUIDE KIT, 66DX

$

$

Not available

531 30 75-19

Husqvarna 531307519

CRANKCASE

$

$

Not available

531 30 75-65

Husqvarna 531307565

COVER, REAR, KIT

$

$

Not available
