14AP805K730 - Huskee Garden Tractor (2006) (Tractor Supply) Frame Parts Diagram

Garden Tractor

Frame Parts Diagram

  • Title

1

MTD 17962

Plate, Switch

$4.99

$

In Stock, Qty 5

0

2

MTD 683-04173

Frame Assembly, Lower
(Superseded to 683-04173B-0637)

Variations

MTD 683-04173-0637

FRAME ASM-LOWER - POWDER BLACK (0637)

$

$

Not available

$

$

3

MTD 683-04219

Bumper Assembly
(Superseded to 683-04219B-0637)

Variations

MTD 683-04219-0637

Bumper Assembly, Universal - POWDER BLACK (0637)

$57.99

$

In Stock, only 4 left!

0

$57.99

$

In Stock, only 4 left!

0

4

MTD 710-0224

Screw, Hex Washer, 10-16 x .5
(Superseded to 910-0224)

$3.49

$

Usually ships in 3-6 days

0

5

MTD 710-0726

Screw, Self-tapping, 5/16-18, 0.75

$3.99

$

In Stock, Qty 20+

0

6

MTD 710-1260A

Screw, Self-tapping, 5/16-12, 0.75

$3.49

$

In Stock, Qty 20+

0

7

MTD 710-1652

Screw, Hex Washer, 1/4-20 x 0.625

$3.99

$

In Stock, Qty 20+

0

8

MTD 711-0332

Pin, Clevis, .50 Dia x .78 Lg
(Superseded to 911-0332)

$14.99

$

In Stock, Qty 20+

0

9

MTD 712-04065

Nut, Nylon Lock, 3/8-16

$3.99

$

In Stock, Qty 20+

0

10

MTD 710-0607

Screw, Hex Wash. Tapp, 5/16-18 x .5

$6.49

$

In Stock, Qty 20+

0

11

MTD 714-04023

Pin, Internal Cotter

$3.99

$

In Stock, Qty 20+

0

12

MTD 725-04039

Switch, Interlock
(Superseded to 925-04039)

$22.99

$

In Stock, Qty 20+

0

13

MTD 732-04035

Spring, Compression, 1.28 OD x 3.125

$9.99

$

In Stock, Qty 15

0

14

MTD 736-0222

Washer, Lock, Ext 1/4

$5.49

$

In Stock, only 3 left!

0

16

MTD 738-04058

Shoulder Spacer

$4.49

$

In Stock, Qty 7

0

17

MTD 738-0143

Shoulder Screw, 3/8-16

$3.99

$

In Stock, Qty 20+

0

18

MTD 710-3005

Hex Screw 3/8-16 x 1.25

$3.99

$

In Stock, Qty 20+

0

19

MTD 783-0726E

Bracket, Pivot, Support RH

Variations

MTD 783-0726E-0606

Pivot Support Bracket, RH - MAJESTIC ORANGE (0606)

$

$

Not available

MTD 783-0726E-0498

Pivot Support Bracket, RH - OLD CUB YELLOW (0498)

$

$

Not available

MTD 783-0726E-0637

BRACKET:PIVOT:SUPT - POWDER BLACK (0637)

$

$

Not available

MTD 783-0726E-0650

BRACKET:PIVOT:SUPT - RED METALLIC (0650)

$

$

Not available

MTD 783-0726E-0691

BRACKET:PIVOT:SUPT - BLACK JACK (0691)

$

$

Not available

MTD 783-0726E-0716

Pivot Support Bracket, RH - CUB YELLOW-99 (0716)

$

$

Not available

MTD 783-0726E-0665

BRACKET:PIVOT:SUPT - YARDMAN GREEN (0665)

$

$

Not available

MTD 783-0726E-4008

BRACKET:PIVOT:SUPT - WINE RED (4008)

$

$

Not available

$

$

20

MTD 783-0727D

Bracket, Pivot, Support LH

Variations

MTD 783-0727D-0606

BRACKET:PIVOT:SUPT - MAJESTIC ORANGE (0606)

$

$

Not available

MTD 783-0727D-0498

Pivot Support Bracket, LH - OLD CUB YELLOW (0498)

$

$

Not available

MTD 783-0727D-0637

BRACKET:PIVOT:SUPT - POWDER BLACK (0637)

$

$

Not available

MTD 783-0727D-0650

BRACKET:PIVOT:SUPT LH - RED METALLIC (0650)

$

$

Not available

MTD 783-0727D-0691

BRACKET:PIVOT:SUPT - BLACK JACK (0691)

$

$

Not available

MTD 783-0727D-0716

Pivot Support Bracket, LH - CUB YELLOW-99 (0716)

$

$

Not available

MTD 783-0727D-0665

BRACKET:PIVOT:SUPT - YARDMAN GREEN (0665)

$

$

Not available

MTD 783-0727D-4008

BRACKET:PIVOT:SUPT - WINE RED (4008)

$

$

Not available

$

$

21

MTD 783-0728

Bracket, Pivot, Bar
(Superseded to 783-0728B)

Variations

MTD 783-0728-0637

Pivot Bar Bracket - POWDER BLACK (0637)

$43.99

$

Usually ships in 3-6 days

0

MTD 783-0728-0650

BRACKET-PIVOT BAR - RED METALLIC (0650)

$43.99

$

Usually ships in 3-6 days

0

MTD 783-0728-0665

BRACKET-PIVOT BAR - YARDMAN GREEN (0665)

$43.99

$

Usually ships in 3-6 days

0

MTD 783-0728-0691

BRACKET-PIVOT BAR - BLACK JACK (0691)

$43.99

$

Usually ships in 3-6 days

0

MTD 783-0728-4008

PIVOT BAR BRACKET - WINE RED (4008)

$43.99

$

Usually ships in 3-6 days

0

MTD 783-0728-0498

Pivot Bar Bracket - OLD CUB YELLOW (0498)

$

$

Not available

MTD 783-0728-0716

Pivot Bar Bracket - CUB YELLOW-99 (0716)

$

$

Not available

$38.99

$

Usually ships in 3-6 days

0

22

MTD 783-04811

Frame, Upper
(Superseded to 783-04811C)

Variations

MTD 783-04811-0637

FRAME-UPPER GT - POWDER BLACK (0637)

$

$

Not available

MTD 783-04811-0665

FRAME-UPPER GT - YARDMAN GREEN (0665)

$

$

Not available

MTD 783-04811-0716

FRAME-UPPER GT - CUB YELLOW-99 (0716)

$

$

Not available

$

$

23

MTD 783-04329A

Bracket, Frame, Seat

Variations

MTD 783-04329A-0606

BRACKET-FRAME SEAT - MAJESTIC ORANGE (0606)

$

$

Not available

MTD 783-04329A-0637

BRACKET-FRAME SEAT - POWDER BLACK (0637)

$

$

Not available

MTD 783-04329A-0716

BRACKET-FRAME SEAT - CUB YELLOW-99 (0716)

$

$

Not available

MTD 783-04329A-4008

No Longer Available BRACKET-FR - WINE RED (4008)

$

$

Not available

$

$

24

MTD 712-04064

Nut, Nylon Lock, 1/4-20

$3.99

$

In Stock, Qty 20+

0

25

MTD 710-0599

Screw, Self-tapping, 1/4-20, 0.500

$3.99

$

In Stock, Qty 20+

0

26

MTD 725-1426A

Solenoid, 12V, 100 Amp
(Superseded to 925-1426A)

$24.99

$

In Stock, Qty 20+

0

27

MTD 736-0222

Washer, External Lock, 1/4

$5.49

$

In Stock, only 3 left!

0

28

MTD 710-0642

Screw, Hex. 1/4-20 x .75

$4.49

$

In Stock, Qty 20+

0

29

MTD 725-1750A

Battery, 235 CCA
(Superseded to 925-1707D)

$

$

Not available

30

MTD 712-0324

Nut, Sems, 1/4-20

$3.49

$

In Stock, Qty 20+

0

31

MTD 710-0703

Screw, Carriage, 1/4-20, .75,

$3.99

$

In Stock, Qty 20+

0

32

MTD 747-04121A

Hold-down Rod, Battery

$5.99

$

In Stock, Qty 20+

0

33

MTD 783-0349

Tray, Battery

Variations

MTD 783-0349-4008

TRAY-BATTERY 400 - WINE RED (4008)

$

$

Not available

MTD 783-0349-0606

TRAY-BATTERY 400 S - MAJESTIC ORANGE (0606)

$

$

Not available

MTD 783-0349-0637

Battery Tray, Powder Black - POWDER BLACK (0637)

$

$

Not available

$

$

34

MTD 783-0693

Axle Bracket

Variations

MTD 783-0693-4008

BRACKET-AXLE - WINE RED (4008)

$21.99

$

Usually ships in 3-6 days

0

MTD 783-0693-0637

BRACKET-AXLE - POWDER BLACK (0637)

$22.99

$

Usually ships in 3-6 days

0

$18.99

$

Usually ships in 3-6 days

0

35

MTD 731-05598

Bumper Cap

$

$

Not available
