1648-0 - PowerBoss 4,500 Watt Portable Generator Control Panel Parts Diagram

4,500 Watt Portable Generator

Control Panel Parts Diagram

  • Title

1

Briggs & Stratton B189250GS

COVER, Lid, Control Panel

$106.99

$

Usually ships in 2-12 days

0

2

Briggs & Stratton 189251GS

CONTROL PANEL, Back, Plastic

$243.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton 82538GS

SWITCH, Rocker

$6.99

$

Usually ships in 2-12 days

0

4

Briggs & Stratton 90418GS

OUTLET, 12V DC

$

$

Not available

5

Briggs & Stratton 189520GS

SCREW

$21.99

$

Usually ships in 2-12 days

0

6

Briggs & Stratton 82881GS

WASHER, Lock

$1.99

$

Usually ships in 2-12 days

0

7

Briggs & Stratton 189737GS

METER, Hour
(Superseded to 187028GS)

$67.99

$

Usually ships in 2-12 days

0

8

Briggs & Stratton 43182GS

WASHER, Lock

$3.99

$

Usually ships in 2-12 days

0

9

Briggs & Stratton 51714GS

NUT

$3.49

$

Usually ships in 2-12 days

0

10

Briggs & Stratton 75207GS

BREAKER, Circuit, 20A
(Superseded to 209872GS)

$9.99

$

Usually ships in 2-12 days

0

11

Briggs & Stratton 23365GS

WASHER

$2.99

$

Usually ships in 2-12 days

0

12

Briggs & Stratton 43437GS

OUTLET, 120/240V, 30A

$17.99

$

Usually ships in 2-12 days

0

13

Briggs & Stratton 38150GS

WASHER

$2.99

$

Usually ships in 2-12 days

0

14

Briggs & Stratton 22264GS

WASHER, Lock

$2.99

$

Usually ships in 2-12 days

0

15

Briggs & Stratton 51715GS

NUT

$2.99

$

Usually ships in 2-12 days

0

16

Briggs & Stratton 80409GS

OUTLET, Duplex, 20A

$102.99

$

In Stock, Qty 5

0

17

Briggs & Stratton 189165GS

NUT

$3.49

$

In Stock, only 2 left!

0

18

Briggs & Stratton 189367GS

BOARD, Idle Control

$222.99

$

Usually ships in 2-12 days

0

19

Briggs & Stratton 84028GS

TRANSFORMER, Idle Control

$47.99

$

In Stock, only 2 left!

0

20

Briggs & Stratton 87962GS

BREAKER, Circuit, 10A, 12V

$29.99

$

Usually ships in 2-12 days

0

21

Briggs & Stratton 22694GS

HOUSING, Receptacle

$5.99

$

Usually ships in 2-12 days

0

22

Briggs & Stratton 82308GS

SCREW

$2.99

$

Usually ships in 2-12 days

0

23

Briggs & Stratton 189502GS

HARNESS, Idle Control

$40.99

$

Usually ships in 2-12 days

0
