1648-1 - PowerBoss 4,500 Watt Portable Generator Alternator Parts Diagram

4,500 Watt Portable Generator

Alternator Parts Diagram

  • Title

1

Briggs & Stratton 186059GS

ADAPTER, Mounting, Alternator
(Superseded to 209599GS)

$37.99

$

Usually ships in 2-12 days

0

2

Briggs & Stratton 193623GS

ROTOR

Note: (Includes Item 15)

$

$

Not available

3

Briggs & Stratton 200416AGS

STATOR

$460.99

$

Usually ships in 2-12 days

0

4

Briggs & Stratton 186060GS

RBC, with O-Ring (p/n 189197GS)
(Superseded to 193336GS)

$41.99

$

Usually ships in 2-12 days

0

5

Briggs & Stratton 86308CGS

HHCS, M6 - 1.0 x 130 SEMS

$5.99

$

Usually ships in 2-12 days

0

6

Briggs & Stratton 91825GS

ASSY, Holder, Rectifier/Brush

$

$

Not available

7

Briggs & Stratton 66849GS

TAPTITE, M5 - 0.8 x 16
(Superseded to 49815GS)

$3.99

$

In Stock, only 1 left!

0

8

Briggs & Stratton 22694GS

RECEPTACLE, 6 pin

$6.49

$

In Stock, only 1 left!

0

9

Briggs & Stratton 81917GS

PIN, Roll, 4mm x 10

$3.49

$

Usually ships in 2-12 days

0

10

Briggs & Stratton 193428AGS

ASSY, Wire, Ground

$3.49

$

Usually ships in 2-12 days

0

11

Briggs & Stratton 66849AGS

TAPTITE, M5 - 0.8 x 20

$4.99

$

Usually ships in 2-12 days

0

12

Briggs & Stratton 65795GS

RECTIFIER, Battery Charge

$

$

Not available

13

Briggs & Stratton 200425GS

HARNESS, Wire, Power

$38.99

$

Usually ships in 2-12 days

0

14

Briggs & Stratton 195180ZGS

ASSY, Wire

$3.99

$

Usually ships in 2-12 days

0

15

Briggs & Stratton 65791GS

BEARING

$36.99

$

In Stock, only 1 left!

0
