1695360 - Snapper 42" Snow Thrower Attachment Gearbox Assembly (1732207) Parts Diagram

42" Snow Thrower Attachment

Gearbox Assembly (1732207) Parts Diagram

  • Title

0010

Snapper 1926105

CAPSCREW, 1/4-20 X 2 3/4
(Superseded to 703166)

$6.49

$

Usually ships in 2-12 days

0

0020

Snapper 1960346

CAPSCREW, Hex Head,1/4-20 x 2-1/4
(Superseded to 1960346SM)

$4.99

$

Usually ships in 2-12 days

0

0030

Snapper 1734218

GEAR CASE HALF, Left Hand

$

$

Not available

0040

Snapper 1668971

FITTING, Pipe Plug
(Superseded to 1668971SM)

$4.49

$

Usually ships in 2-12 days

0

0050

Snapper 1612124

GASKET, Gear Case
(Superseded to 1612124SM)

$17.99

$

In Stock, only 1 left!

0

0060

Snapper 1732440

SHAFT, Auger 1 x 12 1/4
(Superseded to 1732440SM)

$53.99

$

Usually ships in 2-12 days

0

0070

Snapper 1723995

SHAFT & TAB ASSEMBLY
(Superseded to 1723995SM)

$121.99

$

Usually ships in 2-12 days

0

0080

Snapper 1612093

SEAL, OIL
(Superseded to 1612093SM)

$10.99

$

In Stock, Qty 6

0

0090

Snapper 1612149

BUSHING, 3/4 x 1
(Superseded to 1612149SM)

$51.99

$

In Stock, Qty 7

0

0100

Snapper 2836098

PIN, Drive Lock, 3/16 X 1-1/2
(Superseded to 2836098SM)

$18.99

$

In Stock, Qty 6

0

0110

Snapper 1612127

COLLAR, Thrust 3/4 x 1 1/2
(Superseded to 1612127SM)

$30.99

$

In Stock, only 2 left!

0

0120

Snapper 1612142

GEAR, Worm
(Superseded to 706853)

$

$

Not available

0130

Snapper 2168111

WASHER, Thrust .76 x 1 3/8
(Superseded to 2168111SM)

$6.99

$

Usually ships in 2-12 days

0

0140

Snapper 2118315

WASHER, Thrust 1 x 1 5/8
(Superseded to 2118315SM)

$9.99

$

In Stock, Qty 7

0

0150

Snapper 1612141

GEAR, Worm
(Superseded to 1612141SM)

$

$

Not available

0160

Snapper 1734219

GEAR CASE HALF, Right Hand

$

$

Not available

0170

Snapper 1930642

NUT, Hex Flange, 1/4-20 Top Lock, Small
(Superseded to 703916)

$4.99

$

In Stock, only 4 left!

0

0180

Snapper 2118118

SEAL, Oil
(Superseded to 2118118SM)

$10.99

$

In Stock, Qty 5

0

0190

Snapper 1732152

ROD, 1/2 x 8 1/4
(Superseded to 1732152SM)

$33.99

$

In Stock, only 1 left!

0

0200

Snapper 2818312

KEY, Woodruff 3/16 x 5/8
(Superseded to 703891)

$4.99

$

In Stock, Qty 20+

0

0210

Snapper 1732991

BUSHING, 1 x 1 1/4
(Superseded to 1732991SM)

$16.99

$

Usually ships in 2-12 days

0

0220

Snapper 2830246

KEY, Woodruff 1/4 x 3/4
(Superseded to 704280)

$4.99

$

In Stock, Qty 10

0

0230

Snapper 1960294

NUT, Hex Flange Whiz Lock Small, 1/4-20
(Superseded to 703233)

$4.49

$

In Stock, only 2 left!

0

--

GREASE, GR-132 (3oz)

Note: (Use with Brass Gears)

$

$

Not available

--

GREASE, Brown Lithium Mobilux EP1 (3oz)

Note: (Use with Steel Gears)

$

$

Not available
