1696669 A-01 - Simplicity 42" Bagging Boot, Blade & Baffle Bagging Boot Parts Diagram

42" Bagging Boot, Blade & Baffle

Bagging Boot Parts Diagram

  • Title

0010-10

Simplicity 054563MA

PIN, Latch

$23.99

$

In Stock, only 2 left!

0

0010-20

Simplicity 1759606YP

BOOT, Bagging
(Superseded to 1759298YP)

$463.99

$

Usually ships in 2-12 days

0

0010-30

Simplicity 703916

NUT, Hex Flange, 1/4-20

$4.99

$

In Stock, only 4 left!

0

0010-40

Simplicity 1960252SM

BOLT, Carriage, 1/4-20 x 5/8

$3.99

$

In Stock, only 2 left!

0

0020

Simplicity 80090390

HARDWARE BAG

Note: (Not a serviceable part. Includes items 0020-10 thru 0020-30. Order components separately)

$

$

Currently unavailable

0020-10

Simplicity 706490

HANDLE, 5 Prong

$14.99

$

In Stock, only 1 left!

0

0020-20

Simplicity 703826

NUT, Nylock, 5/16-18

$3.49

$

In Stock, Qty 17

0

0020-30

Simplicity 703440

BOLT, Carriage, 1/4-20 x 3/4

$3.99

$

In Stock, Qty 9

0

0070

Simplicity 84005357

BAFFLE, Front

$100.99

$

Usually ships in 2-12 days

0

0080

Simplicity 84005360

BAFFLE, Bagging

$130.99

$

Usually ships in 2-12 days

0

0100

Simplicity 5103660YP

SPACER, .32 x 1/2 x .83

$4.99

$

In Stock, only 1 left!

0

0110

Simplicity 703175

BOLT, Carriage, 5/16-18 x 1 3/4

$3.99

$

In Stock, only 2 left!

0

0120

Simplicity 80090391

HARDWARE BAG

Note: (Not a serviceable part. Includes items 0120-10 thru 0120-40. Order components separately)

$

$

Currently unavailable

0210-10

Simplicity 703115

NUT, Flange Nylock, 5/16-18

$3.49

$

In Stock, Qty 17

0

0120-20

Simplicity 704065

BOLT, Carriage, 5/16-18 X 7/8

$4.49

$

In Stock, Qty 12

0

0120-30

Simplicity 1920676SM

CAPSCREW, Hex Head, 7/16-14 X 1

$5.49

$

In Stock, Qty 7

0

0120-40

Simplicity 1656916SM

WASHER, Spring

$7.49

$

In Stock, Qty 20+

0

0140

Simplicity 1759262BMYP

BLADE, 42"

$30.99

$

In Stock, only 3 left!

0

0160

Simplicity 703297

RETAINER, 5/16 X 5/8

$3.99

$

In Stock, Qty 20+

0
