19A40023 (19A40023100) - Cub Cadet 42" 3X Snow Thrower Attachment att2 Spindle Assembly Parts Diagram

42" 3X Snow Thrower Attachment

Spindle Assembly Parts Diagram

  • Title

1

Cub Cadet 918-07070

Spindle Housing

$76.99

$

Usually ships in 3-6 days

0

1

Cub Cadet 684-05104

Spindle Mounting Bracket

Variations

Cub Cadet 684-05104-0637

BRACKET-SPINDLE MTG POWDER BL - POWDER BLACK (0637)

$411.99

$

Usually ships in 3-6 days

0

$333.99

$

Usually ships in 3-6 days

0

1

Cub Cadet 710-1260A

Screw

$3.99

$

In Stock, Qty 20+

0

1

Cub Cadet 712-0417A

HEX NUT

$7.49

$

In Stock, Qty 20+

0

1

Cub Cadet 738-0976

Blade Spindle Shaft

$51.99

$

In Stock, only 1 left!

0

1

Cub Cadet 756-05080

V Pulley 7.25 Dia

$66.99

$

Usually ships in 3-6 days

0

1

Cub Cadet 756-05081

V Pulley 5.57 Dia

$52.99

$

Usually ships in 3-6 days

0

2

Cub Cadet 684-05105

Hanger Bracket

Variations

Cub Cadet 684-05105-0637

BRACKET ASM-HANGER POWDER BL - POWDER BLACK (0637)

$178.99

$

Usually ships in 3-6 days

0

$144.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 710-0347

Hex Screw, 3/8-16 x 1.75

$5.49

$

In Stock, Qty 20+

0

4

Cub Cadet 710-3001

Hex Screw, 3/8-16 x .880

$7.49

$

In Stock, Qty 5

0

5

Cub Cadet 710-3005

Hex Screw, 3/8-16 x 1.25

$4.49

$

In Stock, Qty 20+

0

6

Cub Cadet 710-3144

Hex Screw, 3/8-16 x 2.00

$4.99

$

In Stock, Qty 20+

0

7

Cub Cadet 711-0309A

Clevis Pin, .62

$12.99

$

In Stock, Qty 5

0

8

Cub Cadet 711-06303

Shaft, .375 x 12.3450

$25.99

$

Usually ships in 3-6 days

0

9

Cub Cadet 712-04065

Flange Lock Nut, 3/8-16

$4.49

$

In Stock, Qty 20+

0

10

Cub Cadet 714-0117

Cotter Pin, .148 x 3.00

$4.49

$

In Stock, Qty 15

0

11

Cub Cadet 714-05005

Pin, 7/16-1/2

$5.49

$

In Stock, Qty 20+

0

12

Cub Cadet 732-04927

Extension Spring, 1.25 x 8.5

$24.99

$

In Stock, Qty 20+

0

13

Cub Cadet 736-0262

Flat Washer, .385 x .870 x .092

$4.49

$

In Stock, Qty 20+

0

14

Cub Cadet 736-0518

Thrust Washer, .445 x 1.92 x .060

$11.99

$

Usually ships in 3-6 days

0

15

Cub Cadet 738-04162C

Shoulder Spacer, .8840 x .190

$14.99

$

In Stock, Qty 20+

0

16

Cub Cadet 738-0966A

Shoulder Bolt, 3/8-16 x .50 x .925

$4.99

$

In Stock, Qty 20+

0

17

Cub Cadet 747-06429

Lock Rod, .500

$37.99

$

In Stock, only 2 left!

0

18

Cub Cadet 747-06483

Sprin Rod Hook

$27.99

$

Usually ships in 3-6 days

0

19

Cub Cadet 748-05037

Idler Pivot Shoulder Spacer
(Superseded to 748-05037B)

$5.99

$

In Stock, Qty 20+

0

20

Cub Cadet 954-05076

V-Belt, 114.3

$103.99

$

Usually ships in 3-6 days

0

21

Cub Cadet 756-05034

Idler Pulley, 4.50
(Superseded to 756-05034A)

$48.99

$

In Stock, Qty 20+

0

22

Cub Cadet 956-3045A

Idler Pulley, 5.06

$60.99

$

In Stock, Qty 20+

0

23

Cub Cadet 783-08389

Pulley Cap

$6.49

$

In Stock, Qty 20+

0

24

Cub Cadet 790-00617-0637

Link Bracket

$113.99

$

Usually ships in 3-6 days

0

25

Cub Cadet 790-00629-0637

Idler Pivot Bracket

$62.99

$

Usually ships in 3-6 days

0

26

Cub Cadet 790-00630-0637

Bracket

$36.99

$

Usually ships in 3-6 days

0

27

Cub Cadet 790-00670-0637

Idler Pivot Bracket

$62.99

$

Usually ships in 3-6 days

0

28

Cub Cadet 790-00675

Hanger Bracket Template

$26.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 710-0376

Hex Screw, 5/16-18 x 1.00

$4.49

$

In Stock, Qty 20+

0

30

Cub Cadet 712-04063

Flange Lock Nut, 5/16-18

$4.49

$

In Stock, Qty 20+

0
