1N169 (9863-0) - Generac 10,000 Watt Portable Generator Cradle (10/95) Parts Diagram

10,000 Watt Portable Generator

Cradle (10/95) Parts Diagram

  • Title

1

Briggs & Stratton 93571

18 HP V-Twin engine

$

$

Currently unavailable

2

Briggs & Stratton 93074

Heat shield

$

$

Currently unavailable

3

Briggs & Stratton 77304

Engine support

$

$

Not available

4

Briggs & Stratton 90916

Stator heat shield

$

$

Currently unavailable

5

Briggs & Stratton 80270

Fuel shut-off valve
(Superseded to 192980GS)

$17.99

$

In Stock, Qty 20+

0

6

Briggs & Stratton 78299

Fuel valve bushing
(Superseded to 192980GS)

$17.99

$

In Stock, Qty 20+

0

7

Briggs & Stratton 90878

Fuel tank cap
(Superseded to 846987)

$21.99

$

In Stock, Qty 6

0

8

Briggs & Stratton 35097

Vibration mounts
(Superseded to 35097GS)

$16.99

$

In Stock, only 3 left!

0

9

Briggs & Stratton 78831B

M6-1.0 x 60mm Capscrew
(Superseded to 78831BGS)

$

$

Not available

10

Briggs & Stratton 93615

Fuel tank
(Superseded to 93615GS)

$

$

Not available

11

Briggs & Stratton 92558

Cradle
(Superseded to 92558GS)

$799.99

$

Usually ships in 2-12 days

0

12

Briggs & Stratton 83465

Fuel tank mtg. grommet
(Superseded to 83465GS)

$3.99

$

In Stock, Qty 20+

0

13

-----

#10-24 x 3/8" Screw

$

$

Not available

14

-----

3/8"-16 x 3/4" Capscrew

$

$

Not available

15

-----

3/8" Lockwasher

$

$

Not available

16

-----

3/8"-16 Hex nut

$

$

Not available

17

-----

3/8"-16 x 1-1/4" Capscrew

$

$

Not available

18

-----

M8 Lockwasher

$

$

Not available

19

Briggs & Stratton 39253

M8-1.25 x 16mm Capscrew
(Superseded to 39253GS)

$3.49

$

Usually ships in 2-12 days

0

20

Briggs & Stratton 95962

Control panel assembly
(Superseded to 95962GS)

$

$

Not available

21

Briggs & Stratton 92102

Stepper motor

$

$

Currently unavailable

22

Briggs & Stratton 95350

Stepper motor bracket
(Superseded to 200107GS)

$31.99

$

Usually ships in 2-12 days

0

23

18553621

Ground wire

$

$

Not available

24

Briggs & Stratton 86292

No. 10 Self-driller capscrew
(Superseded to 313085GS)

$4.99

$

In Stock, only 1 left!

0

25

-----

No. 10 Shakeproof washer

$

$

Not available

26

-----

Engine decal

$

$

Not available

28

Briggs & Stratton 92982

Danger! Stop! decal
(Superseded to 194799GS)

$11.99

$

In Stock, only 1 left!

0

30

Briggs & Stratton 94221

Side panel decal
(Superseded to 691640)

$3.49

$

In Stock, only 1 left!

0

31

Briggs & Stratton 92758

Data plate decal
(Superseded to 92758GS)

$2.99

$

Usually ships in 2-12 days

0

32

Briggs & Stratton 77816

Caution! Hot Muffler decal
(Superseded to 77816GS)

$4.99

$

Usually ships in 2-12 days

0

33

Briggs & Stratton 95349

Adjusting plate
(Superseded to 95349GS)

$7.49

$

Usually ships in 2-12 days

0

34

Briggs & Stratton 95348

Bell crank
(Superseded to 95348GS)

$7.99

$

Usually ships in 2-12 days

0

35

Briggs & Stratton 70005

M6 Lockwasher
(Superseded to 70005GS)

$2.99

$

Usually ships in 2-12 days

0

36

Briggs & Stratton 43146

M6-1.0 x 10mm Capscrew
(Superseded to 43146GS)

$7.99

$

Usually ships in 2-12 days

0

37

Briggs & Stratton 93826

Start Instruction Decal
(Superseded to 93826GS)

$14.99

$

Usually ships in 2-12 days

0

38

Briggs & Stratton 74041

M5-0.8 x 20mm Screw

$

$

Currently unavailable

39

Briggs & Stratton 96716

Nylon Washer
(Superseded to 96716GS)

$2.99

$

Usually ships in 2-12 days

0

40

Briggs & Stratton 95920

Stepper Motor-to-Bell Crank Linkage
(Superseded to 95920GS)

$16.99

$

Usually ships in 2-12 days

0

41

Briggs & Stratton 95921

Bell Crank-to-Throttle Linkage
(Superseded to 95921GS)

$12.99

$

Usually ships in 2-12 days

0

42

-----

#10-32 x 3/4" Capscrew

$

$

Not available

43

-----

M5 Flatwasher

$

$

Not available

44

-----

M5 Lockwasher

$

$

Not available

45

Briggs & Stratton 62265

Rubber Grommet
(Superseded to 62265GS)

$8.49

$

Usually ships in 2-12 days

0

46

Briggs & Stratton 84650

Battery tray

$

$

Currently unavailable

47

Briggs & Stratton 44951

Battery Hold Down Bar

$

$

Currently unavailable

48

Briggs & Stratton 45000

1/4"-20 x 7" Bolt
(Superseded to 45000GS)

$11.99

$

Usually ships in 2-12 days

0

49

-----

1/4" Lockwasher

$

$

Not available

50

-----

1/4"-20 Hex nut

$

$

Not available

51

-----

3/8" Shakeproof washer

$

$

Not available

52

Briggs & Stratton 77282

Starter switch

$

$

Not available

53

Briggs & Stratton 78289

Starter switch bracket
(Superseded to 78289GS)

$7.49

$

Usually ships in 2-12 days

0

54

-----

1/4"-20 x 3/4" Capscrew

$

$

Not available

55

Briggs & Stratton 90914

Oil filter adapter

$

$

Not available

56

Briggs & Stratton 70185

Oil filter
(Superseded to 70185GS)

$14.99

$

Usually ships in 2-12 days

0

57

Briggs & Stratton 60108

Low oil pressure switch

$

$

Not available

58

Briggs & Stratton 64182

M6-1.0 x 16mm Capscrew
(Superseded to 64182GS)

$1.99

$

Usually ships in 2-12 days

0

59

Briggs & Stratton 94391

Louvered panel

$37.99

$

Usually ships in 2-12 days

0

62

Briggs & Stratton 93841

Oil sensor heat shield

$

$

Not available

63

-----

#10-32 x 1/4" Screw

$

$

Not available

64

-----

1/4" Flatwasher

$

$

Not available

65

Briggs & Stratton 18253621

Starter wire assembly
(Superseded to 18253621GS)

$28.99

$

Usually ships in 2-12 days

0

66

Briggs & Stratton 18353621

Battery wire assembly
(Superseded to 18353621GS)

$29.99

$

Usually ships in 2-12 days

0

67

Briggs & Stratton 18453621

Ground wire assembly
(Superseded to 18453621GS)

$34.99

$

Usually ships in 2-12 days

0

68

Briggs & Stratton 96378

Spacer
(Superseded to 96378GS)

$7.49

$

Usually ships in 2-12 days

0

69

Briggs & Stratton 96717

Spring
(Superseded to 96717GS)

$58.99

$

Usually ships in 2-12 days

0

70

Briggs & Stratton 81886

STA-BIL decal
(Superseded to 81886GS)

$12.99

$

Usually ships in 2-12 days

0

71

Briggs & Stratton 73054

Fuel shut-off decal

$

$

Not available

72

Briggs & Stratton 68548

Gasket

$

$

Not available
