20758 - Toro Walk-Behind Mower (SN: 002000001 - 002999999) (1982) HOUSING ASSEMBLY Parts Diagram

Walk-Behind Mower

HOUSING ASSEMBLY Parts Diagram

  • Title

1

Toro 12-3270

SCREW

$3.49

$

In Stock, only 2 left!

0

2

Toro 40-2480

Decal-Door

$

$

Not available

3

Toro 33-0410

Door Mulching
(Superseded to 33-0412)

$

$

Not available

4

Toro 33-0470

Door Latch
(Superseded to 47-5551)

$

$

Not available

5

Toro 33-0440

Cover Door
(Superseded to 33-0441)

$11.99

$

Usually ships in 3-6 days

0

6

Toro 32144-32

SCREW

$2.49

$

Usually ships in 3-6 days

0

7

Toro 33-0450

SPRING-COMPRESSION, LATCH

$

$

Not available

8

Toro 33-0430

Inner Tunnel

$

$

Not available

9

Toro 32146-5

Nut
(Superseded to 32153-3)

$6.49

$

Usually ships in 3-6 days

0

10

Toro 33-2380

SHIELD - TRAILING

$59.99

$

Usually ships in 3-6 days

0

11

Toro 25-7740

KNOB-ARM

$4.99

$

In Stock, Qty 12

0

12

Toro 25-7890

SPRING ARM ASM

$

$

Not available

13

Toro 32146-6

Nut
(Superseded to 3296-6)

$1.99

$

In Stock, Qty 20+

0

14

Toro 33-5600

WHEEL & TIRE ASM

$

$

Not available

15

Toro 27-6230

BOLT-WHEEL

$8.49

$

In Stock, only 3 left!

0

16

Toro 25-3440

PIVOT SCREW

$

$

Not available

17

Toro 330400

Pivot Arm

$

$

Currently unavailable

18

Toro 33-0390

PIVOT WASHER

$3.49

$

In Stock, only 2 left!

0

19

Toro 40-1570

Decal

$

$

Not available

20

Toro 38-2650

Wheel & Tire Assembly
(Superseded to 27-6210)

$

$

Not available

21

Toro 8-3539

Housing

$

$

Not available

22

Toro 33-0420

Tunnel Outer
(Superseded to 13-5829)

$

$

Not available

Toro 11-0049

Loose Parts

Note: Not illustrated

$

$

Currently unavailable
