21386x6C - Murray Ultra 21" Walk-Behind Mower (2000) Wheel Assembly Parts Diagram

Ultra 21" Walk-Behind Mower

Wheel Assembly Parts Diagram

  • Title

80

Murray 672320-850

ASSY, FRAME

$

$

Currently unavailable

180

Murray 71152-850

CROSSBAR, FRONT

$

$

Currently unavailable

181

Murray 672279MA

BUSHING

$4.49

$

Usually ships in 2-12 days

0

183

Murray 710270

SCREW

$20.99

$

Usually ships in 2-12 days

0

202

Murray 643790

SUPPORT, AXLE

$3.49

$

Usually ships in 2-12 days

0

203

Murray 643788

BEARING, LIFTER

$

$

Currently unavailable

210

Murray 672277-850

ASSY, CROSSBAR

$

$

Currently unavailable

212

Murray 180077MA

SCREW, 5/16-18 x 0.75
(Superseded to 704287)

$3.99

$

In Stock, Qty 19

0

213

Murray 710205

NUT

$14.99

$

Usually ships in 2-12 days

0

250

Murray 672278MA

LEVER, SPRING

$12.99

$

Usually ships in 2-12 days

0

251

Murray 710274

SCREW

$61.99

$

Usually ships in 2-12 days

0

252

Murray 671297MA

KNOB, HEIGHT ADJ

$6.49

$

In Stock, only 1 left!

0

280

Murray 43721-850

ASSY., LINK LIFTER

$7.99

$

Usually ships in 2-12 days

0

281

Murray 710292

HAIR PIN

$

$

Currently unavailable

282

UNKNOWN

$

$

Not available

283

Murray 711459MA

SPRING, EXTENSION

$9.49

$

Usually ships in 2-12 days

0

284

Murray 71246-823

COVER, REAR

$

$

Currently unavailable

287

Murray 711863

SCREW, 1.4-20X.63

$1.99

$

Usually ships in 2-12 days

0

288

UNKNOWN

$

$

Not available

300

Murray 671134

TIRE & RIM

$

$

Currently unavailable

301

Murray 671134

TIRE & RIM

$

$

Currently unavailable

303

Murray 710140

NUT

$10.99

$

Usually ships in 2-12 days

0

304

Murray 672123

HUB CAP

$

$

Currently unavailable

305

UNKNOWN

$

$

Not available

310

Murray 672123

HUB CAP

$

$

Currently unavailable

590

Murray 071770MA

DEFLECTOR, CHUTE

$21.99

$

In Stock, only 1 left!

0

591

Murray 071769

COVER, MULCH

$

$

Currently unavailable

592

Murray 166X38MA

SPRING, TORSION

$4.99

$

In Stock, only 2 left!

0

593

Murray 340827 Z

ROD, PIVOT

$

$

Currently unavailable

594

Murray 710285

CAP, PUSH ON
(Superseded to 231739)

$17.99

$

In Stock, only 2 left!

0

595

Murray 712012

SEAL, FOAM

$

$

Not available

620

Murray 071250MA

PLUG, MULCHER

$97.99

$

In Stock, only 1 left!

0
