21500 - Toro Guardian Walk-Behind Mower (SN: 004000001 - 004999999) (1974) HANDLE ASSEMBLY Parts Diagram

Guardian Walk-Behind Mower

HANDLE ASSEMBLY Parts Diagram

  • Title
1

Toro Part# 5-8679

Grass Bag (Incl. Ref. No. 24)
Usually ships same day

Not available

$

$

2

Toro Part# 20-4650

HANDLE-GRASS CHUTE
Usually ships same day

Not available

$

$

Usually ships same day

Currently unavailable

$

$

4

Toro Part# 6-1089

Grass Chute Assembly (Incl. Ref. No. 2-3 & 23)
Usually ships same day

Not available

$

$

5

Toro Part# 22-6110

Bag Rod
(Superseded to 19-4210)
Usually ships in 5 to 8 days

$

$82.16

0

Usually ships same day

Not available

$

$

7

Toro Part# 17-4390

Upper Handle
(Superseded to 17-4400)
Usually ships in 5 to 8 days

$

$162.33

0

8

Toro Part# 17-4510

Control Plate
Usually ships same day

Not available

$

$

9

Toro Part# 20-2700

Decal Control Plate
Usually ships same day

Currently unavailable

$

$

10

Toro Part# 20-4600

Control Throttle
(Superseded to 46-6010)
Usually ships in 5 to 8 days

$

$49.15

0

11

Toro Part# 17-4800

Decal, Safety
Usually ships same day

Currently unavailable

$

$

12

Toro Part# 32104-76

SCREW-HWHTF
Usually ships in 1 day

$

$2.23

0

13

Toro Part# 17-7010

Pivot Nut
Usually ships same day

Not available

$

$

14

Toro Part# 17-4680

Latch Pin
Usually ships same day

Not available

$

$

Usually ships same day

Not available

$

$

16

Toro Part# 17-7500

Lower Handle
Usually ships same day

Currently unavailable

$

$

Toro Part# 17-7490

Lower Handle

Note: Not illustrated

Usually ships same day

Currently unavailable

$

$

17

Toro Part# 17-9380

HANDLE PIN

Note: Replacement Parts Only

Usually ships in 5 to 8 days

$

$10.88

0

18

Toro Part# 32146-8

Nut
(Superseded to 32153-4)

Note: Replacement Parts Only

Usually ships in 5 to 8 days

$

$2.38

0

19

Toro Part# 3290-255

PIN-COTTER, HAIR
Usually ships in 5 to 8 days

$

$7.02

0

20

Toro Part# 17-4660

Latch Spring L.H.
Usually ships same day

Currently unavailable

$

$

21

Toro Part# 6-6330

HANDLE SCREW
Usually ships same day

Not available

$

$

22

Toro Part# 17-4670

Latch Spring R.H.
Usually ships same day

Not available

$

$

23

Toro Part# 22-4870

Decal Instructions
Usually ships same day

Currently unavailable

$

$

24

Toro Part# 3-2781

BAG CORD FASTENER
Usually ships in 5 to 8 days

$

$5.37

0
