220 - Poulan Chainsaw, Type 2 (2006-09) Starter - Type 1-3 Parts Diagram

Chainsaw, Type 2

Starter - Type 1-3 Parts Diagram

  • Title

1

Electrolux/AYP 530047963

Assy.- Isolator
(Superseded to 545006036)

$9.99

$

In Stock, Qty 6

0

2

Electrolux/AYP 530047608

Limiter Strap
(Superseded to 530037009)

$

$

Not available

3

Electrolux/AYP 530042082

Spring- Isolator
(Superseded to 545006036)

$9.99

$

In Stock, Qty 6

0

4

Electrolux/AYP 530015123

Washer

$4.99

$

In Stock, only 4 left!

0

5

Electrolux/AYP 530015814

Screw

$6.49

$

In Stock, Qty 20+

0

6

Electrolux/AYP 530036142

Sleeve-AV Spring

$

$

Not available

7

Electrolux/AYP 530047583

Front Handle
(Superseded to 545048001)

$44.99

$

Usually ships in 3-10 days

0

8

Electrolux/AYP 530016179

Screw

$4.99

$

Usually ships in 3-10 days

0

9

Electrolux/AYP 530044834

Bar 16" Quick Adjust
(Superseded to 578138101)

$

$

Not available

9

Electrolux/AYP 530044866

Bar 16" Pro Lam Quick Adj.
(Superseded to 530044834)

$

$

Not available

10

Electrolux/AYP 952051211

Chain-16"
(Superseded to 581562201)

$22.99

$

In Stock, Qty 15

0

11

Electrolux/AYP 530038238

Plate-Bar Mounting

$

$

Not available

12

Electrolux/AYP 530029850

Chain Catcher

$6.49

$

In Stock, Qty 20+

0

13

Electrolux/AYP 530016132

Screw

$6.49

$

In Stock, Qty 10

0

14

Electrolux/AYP 530026119

Check Valve

$4.49

$

In Stock, Qty 18

0

15

Electrolux/AYP 530038264

Plug-Bronze Vent

$6.49

$

In Stock, Qty 6

0

16

Electrolux/AYP 530010846

Oil Cap Ass’y.
(Superseded to 530057236)

$

$

Not available

17

Electrolux/AYP 530023817

Spring-Starter Dog

$6.49

$

In Stock, Qty 5

0

18

Electrolux/AYP 530016080

Screw

$6.49

$

In Stock, Qty 11

0

19

Electrolux/AYP 530015892

Screw

$6.49

$

In Stock, Qty 20+

0

20

Electrolux/AYP 530049335

Fan Housing

$14.99

$

Usually ships in 3-10 days

0

21

Electrolux/AYP 530069232

Rope Kit

$7.49

$

In Stock, Qty 20+

0

22

Electrolux/AYP 530049797

Starter Handle
(Superseded to 530056422)

$

$

Not available

23

Electrolux/AYP 530027531

Recoil Spring
(Superseded to 545008015)

$6.49

$

In Stock, Qty 17

0

24

Electrolux/AYP 530037817

Starter Pulley
(Superseded to 545034301)

$

$

Not available

25

Electrolux/AYP 530015920

Screw

$6.49

$

In Stock, Qty 8

0

26

Electrolux/AYP 530016134

Nut- Flywheel

$6.49

$

Usually ships in 3-10 days

0

27

Electrolux/AYP 530015127

Washer- Flywheel

$6.49

$

Usually ships in 3-10 days

0

28

Electrolux/AYP 530039209

Flywheel Ass’y.
(Superseded to 530063575)

$

$

Not available

29

Electrolux/AYP 530016133

Bolt - Bar

$6.49

$

In Stock, only 4 left!

0

30

Electrolux/AYP 530047192

Fuel Cap Ass’y.
(Superseded to 580940901)

$6.49

$

In Stock, Qty 20+

0

31

Electrolux/AYP 530015922

Nut - "U"-Type

$6.49

$

In Stock, Qty 5

0

32

Electrolux/AYP 530023877

Fitting - Fuel Line

$4.99

$

In Stock, Qty 20+

0

33

Electrolux/AYP 530069216

Kit-Line purge/tank (large dia.)

$6.49

$

In Stock, Qty 20+

0

34

Electrolux/AYP 530047631

Grommet-Cable

$2.49

$

In Stock, only 2 left!

0

35

Electrolux/AYP 530047602

Cable-Throttle

$

$

Not available

36

Electrolux/AYP 530015906

Screw

$6.49

$

In Stock, Qty 9

0

37

Electrolux/AYP 530015886

Screw

$6.49

$

In Stock, Qty 17

0

38

Electrolux/AYP 530047581

Cover-Rear Handle

$4.99

$

Usually ships in 3-10 days

0

39

Electrolux/AYP 530036098

Throttle lockout

$

$

Not available

40

Electrolux/AYP 530036097

Throttle trigger

$4.99

$

In Stock, only 3 left!

0

41

Electrolux/AYP 530015875

Screw

$4.99

$

In Stock, only 3 left!

0

42

Electrolux/AYP 530071385

Isolator Assy. (Upper)
(Superseded to 545006036)

$9.99

$

In Stock, Qty 6

0

43

Electrolux/AYP 530053274

Isolator Assy. (Lower)
(Superseded to 545006036)

$9.99

$

In Stock, Qty 6

0

44

Electrolux/AYP 530047582

Rear Handle

$15.99

$

Usually ships in 3-10 days

0

45

Electrolux/AYP 530071259

Oil Pump Kit

Note: (Incls. 45-48)

$18.99

$

In Stock, only 2 left!

0

46

Electrolux/AYP 530037820

Gear-Worm Spring

$6.49

$

In Stock, only 4 left!

0

47

Electrolux/AYP 530049477

Elbow-Oil Pickup

$4.99

$

In Stock, Qty 5

0

48

Electrolux/AYP 530019206

Seal Block

$6.49

$

Usually ships in 3-10 days

0

49

Electrolux/AYP 530016064

Screw

$4.99

$

In Stock, Qty 8

0

50

Electrolux/AYP 530047663

Oil Pick-up Ass’y

Note: (Incl. 51-53)

$4.99

$

In Stock, Qty 9

0

51

Electrolux/AYP 530038373

Pick-up Oiler

$4.99

$

Usually ships in 3-10 days

0

52

Electrolux/AYP 530037821

Oil Filter
(Superseded to 530056533)

$6.49

$

Usually ships in 3-10 days

0

53

Electrolux/AYP 530030189

Plug-Oil Filter
(Superseded to 530056533)

$6.49

$

Usually ships in 3-10 days

0

54

Electrolux/AYP 530069572

Kit - Switch

$8.99

$

In Stock, only 3 left!

0

55

Electrolux/AYP 530047605

Knob - Choke

$4.99

$

In Stock, Qty 8

0

56

Electrolux/AYP 530049005

Grommet-Choke knob

$2.49

$

Usually ships in 3-10 days

0

57

Electrolux/AYP 530047621

Assy. - Chassis

Note: (incl. 16,29,30,33, and from page two 5,6)

$

$

Not available

58

Electrolux/AYP 530015907

Washer - thrust

$

$

Not available

59

Electrolux/AYP 530047061

Clutch drum assy- with bearing

$17.99

$

In Stock, Qty 11

0

60

Electrolux/AYP 530015611

Washer - Clutch

$6.49

$

In Stock, Qty 20+

0

61

Electrolux/AYP 530014949

Assy. Clutch

Note: (incl 62)

$13.99

$

In Stock, Qty 19

0

62

Electrolux/AYP 530094188

Spring - Clutch
(Superseded to 530014949)

$13.99

$

In Stock, Qty 19

0

63

Electrolux/AYP 530054999

Kit - Chain Brake
(Superseded to 545139915)

$37.99

$

In Stock, only 1 left!

0

64

Electrolux/AYP 530015917

Nut-Bar Mounting

$3.99

$

In Stock, Qty 20+

0
