260 - Poulan Chainsaw, Type 6 (2008-03) Starter - Type 6 Parts Diagram

Chainsaw, Type 6

Starter - Type 6 Parts Diagram

  • Title

1

Electrolux/AYP 530059667

Assy.-Isolator

$

$

Not available

2

Electrolux/AYP 530047608

Limiter Strap
(Superseded to 530037009)

$

$

Not available

3

Electrolux/AYP 530059668

Spring-Isolator
(Superseded to 545006036)

$9.99

$

In Stock, Qty 6

0

4

Electrolux/AYP 530015158

Washer
(Superseded to 530015123)

$4.99

$

In Stock, only 4 left!

0

5

Electrolux/AYP 530016018

Screw

$

$

Not available

6

Electrolux/AYP 530015843

Screw

$6.49

$

In Stock, only 2 left!

0

7

Electrolux/AYP 530047583

Front Handle
(Superseded to 545048001)

$44.99

$

Usually ships in 3-10 days

0

8

Electrolux/AYP 530015940

Screw

$6.49

$

In Stock, Qty 9

0

9

Electrolux/AYP 530015814

Screw

$6.49

$

In Stock, Qty 20+

0

10

Electrolux/AYP 530014381

Kit-Spike Assy

Note: (Incl. #11) (Russia Unit Only)

$9.99

$

In Stock, Qty 16

0

11

Electrolux/AYP 530016439

Screw

$6.49

$

In Stock, only 1 left!

0

12

Electrolux/AYP 530016132

Screw

$6.49

$

In Stock, Qty 10

0

13

Electrolux/AYP 530038238

Plate-Bar Mount.

$

$

Not available

14

Electrolux/AYP 530015814

Screw

$6.49

$

In Stock, Qty 20+

0

15

Electrolux/AYP 530029850

Chain Catcher

$6.49

$

In Stock, Qty 20+

0

16

Electrolux/AYP 530016133

Bolt-Bar

$6.49

$

In Stock, only 4 left!

0

17

Electrolux/AYP 530057236

Assy-Oil Cap

$

$

Not available

18

Electrolux/AYP 530071666

Kit-Oil Vent

$

$

Not available

19

Electrolux/AYP 530016134

Nut-Flywheel

$6.49

$

Usually ships in 3-10 days

0

20

Electrolux/AYP 530016080

Screw

$6.49

$

In Stock, Qty 11

0

21

Electrolux/AYP 530037817

Starter Pulley
(Superseded to 545034301)

$

$

Not available

22

Electrolux/AYP 530015892

Screw

$6.49

$

In Stock, Qty 20+

0

23

Electrolux/AYP 530049335

Housing-Fan

$14.99

$

Usually ships in 3-10 days

0

24

Electrolux/AYP 530069232

Kit - Rope

$7.49

$

In Stock, Qty 20+

0

25

Electrolux/AYP 530056402

Handle-Starter

$6.49

$

In Stock, only 2 left!

0

26

Electrolux/AYP 530027531

Spring-Recoil
(Superseded to 545008015)

$6.49

$

In Stock, Qty 17

0

27

Electrolux/AYP 530015920

Screw

$6.49

$

In Stock, Qty 8

0

28

Electrolux/AYP 530015127

Washer-Flywheel

$6.49

$

Usually ships in 3-10 days

0

29

Electrolux/AYP 530039187

Assy-Flywheel
(Superseded to 530047534)

$

$

Not available

30

Electrolux/AYP 530047192

Assy-Fuel Cap
(Superseded to 580940901)

$6.49

$

In Stock, Qty 20+

0

31

Electrolux/AYP 530023877

Fitting-fuel line

$4.99

$

In Stock, Qty 20+

0

32

Electrolux/AYP 530069216

Kit-Fuel line (large)

$6.49

$

In Stock, Qty 20+

0

33

Electrolux/AYP 530016149

Spring-Switch

$

$

Not available

34

Electrolux/AYP 530015775

Screw

$6.49

$

In Stock, only 2 left!

0

35

Electrolux/AYP 530047581

Cover-Rear Handle

$4.99

$

Usually ships in 3-10 days

0

36

Electrolux/AYP 530015886

Screw

$6.49

$

In Stock, Qty 17

0

37

Electrolux/AYP 530015906

Screw

$6.49

$

In Stock, Qty 9

0

38

Electrolux/AYP 530036098

Throttle Lockout

$

$

Not available

39

Electrolux/AYP 530036097

Trigger-Throttle

$4.99

$

In Stock, only 3 left!

0

40

Electrolux/AYP 530047582

Handle - Rear

$15.99

$

Usually ships in 3-10 days

0

41

Screw

Note: (Refer to Service Reference)

$

$

Not available

42

Assy Isolator-lower

Note: (Refer to Service Reference)

$

$

Not available

43

Electrolux/AYP 530071958

Kit-Isolator (Upper)
(Superseded to 545006036)

$9.99

$

In Stock, Qty 6

0

44

Electrolux/AYP 530015875

Screw

$4.99

$

In Stock, only 3 left!

0

45

Electrolux/AYP 530059668

Spring-Isolator
(Superseded to 545006036)

$9.99

$

In Stock, Qty 6

0

46

Electrolux/AYP 530057473

Lever-Switch

$4.99

$

Usually ships in 3-10 days

0

47

Electrolux/AYP 530057474

Lever-Choke

$6.49

$

In Stock, only 1 left!

0

48

Electrolux/AYP 530049005

Grommet-Knob

$

$

Not available

49

Electrolux/AYP 530015922

Nut-"U"-Type

$6.49

$

In Stock, Qty 5

0

50

Electrolux/AYP 530058733

Assy-Chassis Gold

Note: (Incl.fuel lines and caps)

$

$

Not available

50

Electrolux/AYP 530058730

Assy-Chassis Black

Note: (Incl.fuel lines and caps)

$

$

Not available

51

Electrolux/AYP 530015907

Washer-Thrust

$

$

Not available

52

Electrolux/AYP 530047061

Assy.-Clutch Drum w/bearing

$17.99

$

In Stock, Qty 8

0

53

Electrolux/AYP 530015611

Washer-Clutch

$6.49

$

In Stock, Qty 20+

0

54

Electrolux/AYP 530014949

Assy. Clutch

$13.99

$

In Stock, Qty 18

0

55

Electrolux/AYP 530071259

Kit - Oil Pump

Note: (Incl. 56,57,59)

$18.99

$

In Stock, only 1 left!

0

56

Electrolux/AYP 530037820

Gear-Worm Spring

$6.49

$

In Stock, only 4 left!

0

57

Electrolux/AYP 530049477

Elbow-Oil Pickup

$4.99

$

In Stock, Qty 5

0

58

Electrolux/AYP 530016064

Screw

$4.99

$

In Stock, Qty 6

0

59

Electrolux/AYP 530019206

Seal Block

$6.49

$

Usually ships in 3-10 days

0

60

Electrolux/AYP 530047663

Assy-Oil Pick-up

Note: (Incl. 61,62)

$4.99

$

In Stock, Qty 8

0

61

Electrolux/AYP 530038373

Pick-up Oiler

$4.99

$

Usually ships in 3-10 days

0

62

Electrolux/AYP 530056533

Filter-Oil

$6.49

$

Usually ships in 3-10 days

0

63

Electrolux/AYP 545139915

Assy.-Chain Brake

$37.99

$

In Stock, only 1 left!

0

64

Electrolux/AYP 530015917

Nut-Bar Mounting

$3.99

$

In Stock, Qty 20+

0

65

Electrolux/AYP 530015826

Pin-Bar Adjust

$4.99

$

In Stock, Qty 20+

0

66

Electrolux/AYP 530038593

Retainer

$4.99

$

In Stock, Qty 20+

0

67

Electrolux/AYP 530069611

Kit-Bar Adjusting

Note: (incl. # 65,66)

$4.99

$

In Stock, Qty 20+

0

68

Electrolux/AYP 952051211

Chain 16"
(Superseded to 581562201)

$22.99

$

In Stock, Qty 14

0

68

Electrolux/AYP 952051338

Chain 18"
(Superseded to 581562301)

$25.99

$

In Stock, Qty 12

0

69

Electrolux/AYP 952044369

Bar 16" Standard

Note: (Refer to Service Reference)

$20.99

$

Usually ships in 3-10 days

0

69

Electrolux/AYP 952044689

Bar 18" Standard

$22.99

$

In Stock, Qty 7

0

69

Electrolux/AYP 952044926

Bar 18" Quick Adjust

$

$

Not available

69

Electrolux/AYP 530044867

Bar 18" Quick Adj. pro lam
(Superseded to 530044835)

$

$

Not available
