2690495 - Simplicity Regent 40" Lawn Tractor, 18.5hp Briggs & Stratton 40" Mower Deck - Housing, Arbors & Blades Group Parts Diagram

Regent 40" Lawn Tractor, 18.5hp Briggs & Stratton

40" Mower Deck - Housing, Arbors & Blades Group Parts Diagram

  • Title

1

Simplicity 1723453

DEFLECTOR, Discharge
(Superseded to 1723453SM)

$61.99

$

Usually ships in 2-12 days

0

2

Simplicity 1732085

COVER, Arbor RH Black
(Superseded to 1732085SM)

$47.99

$

Usually ships in 2-12 days

0

3

Simplicity 1930585

CAPSCREW, Hex Flange, 7/16-14 x 3-1/2 G8
(Superseded to 1930585SM)

$7.49

$

In Stock, only 1 left!

0

4

Simplicity 1933263

WASHER
(Superseded to 703990)

$6.99

$

In Stock, only 4 left!

0

5

Simplicity 1656916

WASHER, Spring
(Superseded to 1656916SM)

$7.49

$

In Stock, Qty 20+

0

6

Simplicity 2830584

CAPSCREW, 7/16-14 x 2-3/4 G8
(Superseded to 2830584SM)

$4.99

$

Usually ships in 2-12 days

0

7

Simplicity 1732123

PULLEY, Drive, Shallow-Groove, .49"
(Superseded to 1732123SM)

Note: (Must use with Shallow-Groove Belt)

$35.99

$

Usually ships in 2-12 days

0

-

Simplicity 1733113

PULLEY, Drive, Deep-Groove, .75"

Note: (Must use with Deep-Groove Belt)

$

$

Not available

8

Simplicity 1732051

HUB

$

$

Not available

9

Simplicity 1687229

SPROCKET & FLANGE ASSEMBLY, Riveted, 38 Tooth
(Superseded to 1732590SM)

$87.99

$

In Stock, only 2 left!

0

10

Simplicity 1657969

SHIELD, Bearing Upper, Arbor
(Superseded to 1657969SM)

$7.49

$

In Stock, Qty 10

0

11

Simplicity 1655729A

COVER, Arbor Housing
(Superseded to 1655729ASM)

$14.99

$

In Stock, Qty 20+

0

12

Simplicity 1707335

GASKET, Foam
(Superseded to 1707335SM)

$5.99

$

In Stock, Qty 20+

0

13

Simplicity 1722396

ARBOR SHAFT & BEARINGS ASSEMBLY
(Superseded to 1722396SM)

Note: (Includes Ref. Nos 48& 49)

$263.99

$

In Stock, only 1 left!

0

14

Simplicity 2108202

BEARING, Upper
(Superseded to 2108202SM)

$11.99

$

In Stock, Qty 20+

0

15

Simplicity 1722394

SHAFT, Spline 5.389LG
(Superseded to 1722394SM)

$107.99

$

Usually ships in 2-12 days

0

16

Simplicity 1703273A

HOUSING, Arbor Bottom
(Superseded to 1703273ASM)

Note: (Includes Ref. No 50)

$38.99

$

In Stock, Qty 5

0

17

Simplicity 1704314

FITTING, Grease
(Superseded to 1704314SM)

$4.99

$

In Stock, Qty 20+

0

18

Simplicity 1664847SM

CAPSCREW, Hex Head, Taptite, 5/16-18 x 3/4
(Superseded to 703228)

$4.49

$

In Stock, Qty 20+

0

19

Simplicity 1724601

COVER, Arbor, LH
(Superseded to 1732301SM)

$29.99

$

Usually ships in 2-12 days

0

20

Simplicity 1731992C

HOUSING ASSEMBLY, 40" Mulcher Orange

$

$

Not available

21

Simplicity 1960373

CAPSCREW, Taptite Hex Washer Head, 5/16-18 x 1
(Superseded to 704146)

$3.99

$

In Stock, Qty 20+

0

22

Simplicity 1722258

PIN, Blade
(Superseded to 1722258SM)

$8.49

$

In Stock, Qty 9

0

23

Simplicity 1719624A

BLADE, Mower 40" Mower LH
(Superseded to 1719624ASM)

$31.99

$

In Stock, only 2 left!

0

24

Simplicity 2827120

CAPSCREW, Hex Head, 7/16-14 x 2-1/4 G8
(Superseded to 2827120SM)

$5.99

$

In Stock, only 1 left!

0

25

Simplicity 1722257

WASHER, Spline
(Superseded to 1722257SM)

$59.99

$

Usually ships in 2-12 days

0

26

Simplicity 1719623A

BLADE, Mower 40" Mower RH
(Superseded to 1719623ASM)

$31.99

$

In Stock, only 1 left!

0

27

Simplicity 1655777

ADAPTOR, Blade
(Superseded to 1655777SM)

$25.99

$

In Stock, Qty 20+

0

28

Simplicity 1700229

SHIELD, Bearing
(Superseded to 1700229SM)

$10.99

$

In Stock, Qty 15

0

29

Simplicity 1700230

WASHER, Shim
(Superseded to 1700230SM)

$4.99

$

In Stock, Qty 20+

0

30

Simplicity 1677274A

ADAPTOR, Arbor
(Superseded to 1677274ASM)

$20.99

$

Usually ships in 2-12 days

0

31

Simplicity 1931318

CARRIAGE BOLT, 1/4-20 x 7/8
(Superseded to 1931318SM)

$4.49

$

In Stock, only 4 left!

0

32

Simplicity 1960518

NUT, Push On
(Superseded to 703826)

$3.49

$

In Stock, Qty 8

0

33

Simplicity 1960353

WASHER, Plain, 1/4 (6 Total for Export)
(Superseded to 703229)

$4.49

$

In Stock, only 2 left!

0

34

Simplicity 1704873

CLAMP
(Superseded to 1704873SM)

$4.49

$

In Stock, only 4 left!

0

35

Simplicity 1920397

NUT, Hex, 1/4-20
(Superseded to 703232)

$4.49

$

In Stock, Qty 20+

0

36

Simplicity 1719597

DOOR, Mulching, Black Plastic
(Superseded to 1719597SM)

$32.99

$

Usually ships in 2-12 days

0

37

Simplicity 1723938

SPRING
(Superseded to 1723938SM)

$6.49

$

Usually ships in 2-12 days

0

38

Simplicity 1931335

CARRIAGE BOLT, 5/16-18 x 1
(Superseded to 703800)

$3.99

$

In Stock, Qty 16

0

39

Simplicity 1933988

NUT, Push
(Superseded to 703297)

$3.99

$

In Stock, Qty 20+

0

40

Simplicity 1719617

ROD, Pivot
(Superseded to 1719617SM)

$10.99

$

Usually ships in 2-12 days

0

41

Simplicity 1919381

WASHER, Plain, 5/16
(Superseded to 1919381SM)

$4.49

$

In Stock, Qty 11

0

43

Simplicity 1919438

NUT, Hex ESNA 5/16-18
(Superseded to 1919438SM)

$3.99

$

In Stock, Qty 9

0
