281 (190-281-100) - Cub Cadet Cruise Control Series 1000 Cruise Control Kit Parts Diagram

Cruise Control

Series 1000 Cruise Control Kit Parts Diagram

  • Title

1

Cub Cadet 1111599

Screw, 1/4-20 x 5/8
(Superseded to 710-0751)

$4.49

$

In Stock, Qty 20+

0

2

Cub Cadet 1120210

Drive Pin, 3/16 x 1

$

$

Not available

3

Cub Cadet 1185985

Keps Nut, #10-24
(Superseded to 712-0272)

Note: (not shown)

$4.49

$

In Stock, only 2 left!

0

4

Cub Cadet 1186396

Whiz Locknut

$

$

Not available

5

Cub Cadet 1720883

Washer

$

$

Not available

6

Cub Cadet 1734398

Top Locknut, 1/4-20
(Superseded to 912-0291)

Note: (not shown)

$

$

Not available

7

Cub Cadet 1748723

Push-button Switch

$

$

Not available

8

Cub Cadet 1749907

Speed Control Relay

$

$

Not available

9

Cub Cadet 1750736

Special Screw

$30.99

$

Usually ships in 3-6 days

0

10

Cub Cadet 1754675

Magnet
(Superseded to 1768971)

Note: (includes Spring)

$183.99

$

Usually ships in 3-6 days

0

11

Cub Cadet 1758070

Sems Screw, 10-24 x 5/8
(Superseded to 710-0425)

$5.49

$

Usually ships in 3-6 days

0

12

Cub Cadet 1766290

Upper Cruise Arm Assembly

$

$

Not available

13

Cub Cadet 1766334

Cruise Control Plate

$

$

Not available

14

Cub Cadet 1766350

Cruise Control Switch

$

$

Not available

15

Cub Cadet 1766351

Cruise Control Harness

$

$

Not available

16

Cub Cadet 1766984

Thread-Cutting Screw, 5/16-18 x 3/4

$3.99

$

Usually ships in 3-6 days

0

17

Cub Cadet 1767803

Lower Cruise Arm Assembly

$

$

Not available

18

Cub Cadet 1767822

Extension Spring

$

$

Not available

19

Cub Cadet 1767852

Connector

$

$

Not available

20

Cub Cadet 1735531

Wire Tie
(Superseded to 725-0157)

$3.99

$

In Stock, Qty 20+

0

201

Cub Cadet 1764897

Indicator Light Bulb

$

$

Not available
