3000 (5900530) - Massey Ferguson 52" Zero-Turn Mower Wheel & Tire Group Parts Diagram

52" Zero-Turn Mower

Wheel & Tire Group Parts Diagram

  • Title

1

Simplicity 5022631S

TIRE, CASTER, 13 X 5.00-6
(Superseded to 5022631SSM)

$172.99

$

In Stock, only 3 left!

0

2

Simplicity 5047103

ADAPTER, CASTER AXLE, CZ
(Superseded to 5047103SM)

Note: (S/N: 2016230844 & Below)(2 per tire)

$11.99

$

In Stock, Qty 20+

0

3

Simplicity 5025017X64

BOLT, 1/2-13 x 8"
(Superseded to 5025017X64SM)

$10.99

$

In Stock, only 2 left!

0

4

Simplicity 5025396

NUT, 1/2-13 HEX NYLOCK FLANGE
(Superseded to 770225)

$3.49

$

In Stock, Qty 18

0

5

Simplicity 5025158

WASHER, 1/2 SAE
(Superseded to 5025158SM)

$4.49

$

In Stock, Qty 20+

0

6

Simplicity 5103041

TIRE ASSM, 22X11.00-10, .75 NEG
(Superseded to 5103041YP)

$381.99

$

Usually ships in 2-12 days

0

7

Simplicity 5023369X2

TIRE, 22 X 11.00-10, 4 PLY
(Superseded to 5023369SM)

$437.99

$

Usually ships in 2-12 days

0

8

Simplicity 5102771X1

WHEEL, 10 X 7, .75NEG OFFSET
(Superseded to 5102771X1YP)

$110.99

$

Usually ships in 2-12 days

0

9

Simplicity 5020601

NUT, 1/2-20, FOR WHEEL BOLT SILVER
(Superseded to 5020601SM)

$3.49

$

Usually ships in 2-12 days

0

10

Simplicity 5022029X1

TIRE, 13 X 5.0 - 6
(Superseded to 5022631SSM)

$172.99

$

In Stock, only 3 left!

0

11

Simplicity 5022631SX1

WHEEL ASSEMBLY, 13 X 5 - 6 TIRE
(Superseded to 5022631SX1SM)

$105.99

$

Usually ships in 2-12 days

0

12

Simplicity 5022631SX2

BEARING, Tapered Roller
(Superseded to 5022631SX2SM)

$13.99

$

In Stock, Qty 17

0

13

Simplicity 5022631SX3

SEAL, GREASE
(Superseded to 5022631SX3SM)

$9.99

$

In Stock, Qty 18

0

14

Simplicity 5022631SX4

BEARING, RACE
(Superseded to 5022631SX4SM)

$10.99

$

In Stock, only 3 left!

0

15

Simplicity 5103650

NUT, BEARING ADJUSTER, AXLE
(Superseded to 5103650YP)

Note: (S/N: 2016230845 & Above)(2 per tire)

$16.99

$

In Stock, only 1 left!

0

16

Simplicity 5103648

AXLE, BEARING ADJUSTER, 6.0"
(Superseded to 5103648FS)

Note: (S/N: 2016230845 & Above)(1 per tire)

$23.99

$

Usually ships in 2-12 days

0

17

Simplicity 5103594

DEBRIS COVER, CASTER WHEELS
(Superseded to 5103594YP)

Note: (S/N: 2016230845 & Above)(2 per tire)

$4.99

$

In Stock, Qty 20+

0
