30721 - Toro 72" Side-Discharge Rear-Engine Riding Mower (SN: 001000001 - 001999999) (1981) NOZZLE & HOLDER ASSEMBLY NO. 42-8110 Parts Diagram

72" Side-Discharge Rear-Engine Riding Mower

NOZZLE & HOLDER ASSEMBLY NO. 42-8110 Parts Diagram

  • Title

1

Toro 42-8640

Nipple

$

$

Not available

2

Toro 42-9670

Washer

$

$

Not available

3

Toro 42-8610

Body
(Superseded to 44-8070)

$

$

Not available

4

Toro 42-8670

FLANGE

$

$

Not available

5

Toro 42-9680

WASHER

$

$

Not available

Toro 42-9690

WASHER

Note: Not illustrated

$

$

Not available

Toro 42-9700

WASHER

Note: Not illustrated

$

$

Not available

Toro 42-9710

Washer O.9T

Note: Not illustrated

$

$

Not available

Toro 42-9720

WASHER

Note: Not illustrated

$

$

Not available

Toro 42-9730

WASHER

Note: Not illustrated

$

$

Not available

Toro 42-9740

WASHER

Note: Not illustrated

$

$

Not available

Toro 42-9750

WASHER

Note: Not illustrated

$

$

Not available

6

Toro 42-8630

Spring Pressure
(Superseded to 51-7500)

$

$

Not available

7

Toro 42-8620

PRESSURE PIN MM500135

$

$

Not available

8

Toro 42-8660

Piece-Distance
(Superseded to 51-7520)

$

$

Not available

9

Toro 42-8680

NOZZLE ASM

$

$

Not available

10

Toro 42-8650

RET NUT

$

$

Not available
