31340-8 - MTD Snow Thrower (1988) Snow Parts Diagram

Snow Thrower

Snow Parts Diagram

  • Title

1

MTD 05988

Clutch Grip Ass'y. R.H.

$

$

Not available

2

MTD 720-0180

Hand Grips
(Superseded to 720-04083)

$13.99

$

In Stock, only 3 left!

0

3

MTD 746-0367

Lockout Cable 30.5" Lg.
(Superseded to 946-0367)

$37.99

$

Usually ships in 3-6 days

0

4

MTD 741-0402

Hex Flange Brg. Plastic .38" I.D.

$

$

Not available

6

MTD 731-0496

Plastic Plug

$

$

Not available

7

MTD 710-0487

Carriage Bolt 5/16-18 x 2.0" Lg.

$6.99

$

Usually ships in 3-6 days

0

8

MTD 714-0104

Internal Cotter Pin

$3.99

$

In Stock, Qty 20+

0

9

MTD 05987

Clutch Grip Ass'y. L.H.

$

$

Currently unavailable

10

MTD 738-0560

Shld Bolt .374" Dia. x 1.53" Lg.
(Superseded to 938-0560)

$9.99

$

In Stock, only 2 left!

0

11

MTD 749-0593

Upper Handle Half L.H.

$

$

Not available

12

MTD 09966

Hand Knob
(Superseded to 720-04072A)

$6.49

$

In Stock, Qty 20+

0

13

MTD 736-0242

Belleville Wash. 5/16" I.D.

$3.99

$

In Stock, Qty 20+

0

14

MTD 726-0100

Push Nut 3/8" Rod

$3.99

$

In Stock, Qty 7

0

15

MTD 720-0201

Knob 3/8" I.D.
(Superseded to 720-0201A)

$10.99

$

In Stock, Qty 6

0

16

MTD 715-0138

Roll Pin .12 Dia. x .63" Lg.
(Superseded to 915-0138)

$4.49

$

In Stock, only 1 left!

0

17

MTD 747-0416

Eyebolt

$

$

Not available

18

MTD 05980

Chute Crank Ass'y.

$

$

Not available

19

MTD 712-0267

Hex Nut 5/16-18 Thd.
(Superseded to 912-3010)

$4.49

$

In Stock, Qty 20+

0

21

MTD 741-0475

Plastic Bushing
(Superseded to 941-0475)

$3.99

$

In Stock, Qty 20+

0

22

MTD 747-0356

Shifting Rod

$

$

Not available

23

MTD 749-0343

Lower Handle Half L.H.

$

$

Not available

24

MTD 732-0184

Extension Spring .75" O.D. x 5.0" Lg.

$23.99

$

Usually ships in 3-6 days

0

25

MTD 712-0324

Hex Ins. L-Nut 1/4-20 Thd.

$3.49

$

In Stock, Qty 20+

0

26

MTD 05898

Shifting Linkage Bracket

$

$

Not available

27

MTD 736-0105

Belleville Wash. .40 I.D. x .88 O.D. x .060

$3.99

$

In Stock, Qty 20+

0

28

MTD 710-0427

Hex Bolt 3/8-16 x 2.0" Lg.
(Superseded to 710-3144)

$4.49

$

In Stock, Qty 20+

0

29

MTD 710-0623

Hex Wash. Hd. Self-Tap Scr. 3/8-16 x .75" Lg.

$3.99

$

In Stock, Qty 8

0

30

MTD 05899

Frame Cover

$

$

Currently unavailable

31

MTD 710-0599

Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .50" Lg.

$3.99

$

In Stock, Qty 20+

0

32

MTD 732-0320

Extension Spring .38" O.D. x 3.25" Lg.
(Superseded to 932-0320)

$9.99

$

In Stock, only 3 left!

0

33

MTD 712-0342

Hex Jam Nut 3/8-16 Thd.
(Superseded to 912-3008)

$4.49

$

In Stock, Qty 20+

0

34

MTD 736-0169

L-Wash. 3/8" I.D.

$3.49

$

In Stock, Qty 20+

0

35

MTD 784-5050

Auger Clutch Brkt. Ass'y.

$

$

Not available

36

MTD 738-0281

Shld. Bolt .625" Dia. x .170" Lg. (3/8-16)

$9.99

$

In Stock, only 1 left!

0

37

MTD 732-0320

Extension Spring .38" O.D. x 3.25" Lg.
(Superseded to 932-0320)

$9.99

$

In Stock, only 3 left!

0

38

MTD 05878

Drive Pulley Support Brkt. Ass'y.

$

$

Currently unavailable

39

MTD 714-0507

Cotter Pin 3/32" Dia. x .75" Lg.

$4.49

$

In Stock, only 4 left!

0

40

MTD 05501

Drlve Clutch Brkt.

$

$

Not available

41

MTD 10080

Drive Clutch Rod

$

$

Not available

42

MTD 749-0344

Lower Handle Half R.H.

$

$

Not available

43

MTD 738-0561

Shld. Nut 1/4-20 Thd.
(Superseded to 938-0561)

$9.49

$

In Stock, only 1 left!

0

45

MTD 05805

Shift Handle Ass'y.

$

$

Not available

46

MTD 712-0116

Hex Ins. Jam L-Nut 3/8-24 Thd.

$4.49

$

In Stock, Qty 7

0

47

MTD 732-0193

Compression Spring .38" O.D. x .88" Lg.

$4.49

$

In Stock, Qty 8

0

48

MTD 736-0105

Bell-Wash. .40 I.D. x .88 O.D. x .060

$3.99

$

In Stock, Qty 20+

0

49

MTD 714-0507

Cotter Pin 3/32" Dia. x .75" Lg.

$4.49

$

In Stock, only 4 left!

0

50

MTD 784-5139

Handle Panel Ass'y.

$

$

Not available

51

MTD 749-0594

Upper Handle Half R.H.

$

$

Not available

52

MTD 736-0219

Bell-Wash. .38 I.D. x 1.12" O.D. x .02
(Superseded to 936-0219)

$3.99

$

In Stock, only 1 left!

0

54

MTD 710-0116

Hex Bolt 5/16-18 x 2" Lg.
(Superseded to 710-3103)

$4.49

$

In Stock, Qty 19

0

55

MTD 746-0435

Lockout Cable 36" Lg.
(Superseded to 946-0435)

$42.99

$

In Stock, only 2 left!

0

56

MTD 711-0736

Adjustment Ferrule

$13.99

$

In Stock, only 2 left!

0

57

MTD 736-0264

Fl-Wash. .33" I.D. x .63" O.D.

$6.49

$

In Stock, only 2 left!

0
