327 (190-327-100) - Cub Cadet 38" Triple Rear Bagger att Discharge Chute & High Lift Blades Parts Diagram

38" Triple Rear Bagger

Discharge Chute & High Lift Blades Parts Diagram

  • Title

1

Cub Cadet 731-0825

Elbow, Catcher

$

$

Not available

2

Cub Cadet 703-1989

Tube Assy, Catcher, 28.0 Lg

$

$

Not available

Cub Cadet 710-0946

Screw, Truss Mach, 1/4-20 X .62 Lg

$3.49

$

Usually ships in 3-6 days

0

Cub Cadet 712-0324

Nut, Hex Insert Lock, 1/4-20

$3.49

$

In Stock, Qty 20+

0

3

Cub Cadet 731-3071

Chute, Discharge

$167.99

$

Usually ships in 3-6 days

0

4

Cub Cadet 723-0383

Strap Assy, Retainer
(Superseded to 923-0383)

$14.99

$

In Stock, Qty 13

0

5

Cub Cadet 710-0289

Screw, Hex, 1/4-20 X .50 Lg
(Superseded to 910-0289)

$3.49

$

Usually ships in 3-6 days

0

6

Cub Cadet 712-0324

Nut, Hex Insert Lock, 1/4-20

$3.49

$

In Stock, Qty 20+

0

7

Cub Cadet 736-0175

Washer, Spring, .265 ID X .562 OD
(Superseded to 936-0175)

$3.99

$

In Stock, only 3 left!

0

8

Cub Cadet 16606

Hook Bracket, Retainer
(Superseded to 96606)

$6.99

$

In Stock, Qty 14

0

9

Cub Cadet 710-0258

Screw, Hex Cap, 1/4-20 X .62 Lg
(Superseded to 710-0751)

$3.99

$

In Stock, Qty 20+

0

10

Cub Cadet 723-3052

Strap Assy, Chute Retainer

$25.99

$

Usually ships in 3-6 days

0

11

Cub Cadet 742-3008

Blade, Mower - High Lift
(Superseded to 759-3816)

$34.99

$

In Stock, Qty 14

0
