3340 - International Harvester 19" Push Power Mower (1977 - 1983) Mower Housing, Cutting Blade, Rear Shield And Wheels Parts Diagram

19" Push Power Mower

Mower Housing, Cutting Blade, Rear Shield And Wheels Parts Diagram

  • Title

1

Cub Cadet IH-73513-C1

DEFLECTOR

$

$

Currently unavailable

2

Cub Cadet IH-73191-C1

SCREW

$

$

Not available

3

Cub Cadet IH-73514-C1

SPRING, HINGE

$

$

Currently unavailable

4

Cub Cadet IH-73524-C1

ARM, PIVOT - LEFT FRONT, RIGHT REAR

$

$

Currently unavailable

5

Cub Cadet IH-73533-C1

SPACER, HANDLE LATCH

$

$

Currently unavailable

6

Cub Cadet IH-73532-C1

LATCH, HANDLE

$

$

Currently unavailable

7

Cub Cadet IH-79723-C1

BOLT, SHOULDER

Note: (SERIAL NO 13851 THRU 15451 ONLY)

$

$

Currently unavailable

7

Cub Cadet IH-73534-C1

SCREW, SHOULDER

Note: (SERIAL NO. 13850 & BELOW, SERIAL NO. 15452 & ABOVE)

$

$

Not available

8

Cub Cadet IH-73519-C1

PLUG, WASH-OUT

$

$

Currently unavailable

9

Cub Cadet IH-73530-C1

NUT

$

$

Currently unavailable

10

Cub Cadet IH-73516-C1

SHIELD, REAR

$

$

Currently unavailable

11

Cub Cadet IH-73517-C1

SCREW

$

$

Currently unavailable

12

Cub Cadet IH-73523-C1

NUT, LOCK

$

$

Currently unavailable

13

Cub Cadet IH-73520-C1

WHEEL W/TIRE, FRONT

$

$

Not available

13

Cub Cadet IH-73531-C1

WHEEL W/TIRE, REAR

$

$

Not available

14

Cub Cadet IH-73521-C1

BOLT, WHEEL

$

$

Not available

Cub Cadet IH-73522-C1

WASHER, BOLT

$

$

Currently unavailable

15

Cub Cadet IH-73525-C1

ARM, PIVOT -RIGHT FRONT, LEFT REAR

$

$

Not available

16

Cub Cadet IH-73540-C1

BLADE, 19 IN. CUTTING

$

$

Not available

17

Cub Cadet IH-73538-C1

RETAINER, BLADE

$

$

Currently unavailable

18

Cub Cadet IH-73542-C1

BOLT, BLADE

$

$

Currently unavailable

19

Cub Cadet IH-103328

WASHER, 7/16 PLN HV LOCK

$

$

Currently unavailable

20

Cub Cadet IH-73541-C1

CUP, ANTI-SCALP

$

$

Not available

21

Cub Cadet IH-431787

KEY, 3/16 X 5/8 WOODRUFF 61

$

$

Not available

22

Cub Cadet IH-9411638

NUT, 5/16 CAD P/T LOCK TYPE 1

$

$

Currently unavailable

23

Cub Cadet IH-73510-C1

HOUSING, MOWER

$

$

Currently unavailable

24

Cub Cadet IH-71961-C1

WASHER

$

$

Currently unavailable

25

Cub Cadet IH-73529-C1

BOLT, PIVOT

$

$

Currently unavailable

26

Cub Cadet IH-73527-C1

ARM, SPRING

$

$

Not available

27

Cub Cadet IH-73528-C1

KNOB, ARM

$

$

Currently unavailable
