375Z (EZT 2050) (5900735) - Snapper 50" Zero-Turn Mower, 20hp Electrical Group Parts Diagram

50" Zero-Turn Mower, 20hp

Electrical Group Parts Diagram

  • Title

1

Snapper 1686734

SWITCH, IGNITION,
(Superseded to 1686734SM)

Note: (Set of 2)

$32.99

$

In Stock, Qty 20+

0

2

Snapper 1717163

KEY, IGNITION MOLDED
(Superseded to 1717163SM)

$8.99

$

In Stock, Qty 13

0

3

Snapper 1704346

COVER
(Superseded to 1704346SM)

$4.49

$

In Stock, only 1 left!

0

4

Snapper 5022791

PLASTIC NUT
(Superseded to 5022791SM)

Note: (Includes Retaining Ring)

$3.49

$

Usually ships in 2-12 days

0

5

Snapper 1731184

HOUR METER, DIGITAL
(Superseded to 1731184SM)

$64.99

$

In Stock, only 2 left!

0

6

Snapper 1722887

SWITCH, PTO
(Superseded to 1722887SM)

$33.99

$

In Stock, Qty 20+

0

7

Snapper 5400371

WIRE HARNESS, SNAPPER Z
(Superseded to 5400371SM)

$347.99

$

Usually ships in 2-12 days

0

8

Snapper 5023488

BATTERY CABLE, POSITIVE, 22"
(Superseded to 5023488SM)

$27.99

$

Usually ships in 2-12 days

0

9

Snapper 1716368

SWITCH, SEAT, GRAY, NC (BOLT IN)
(Superseded to 5100540)

$32.99

$

Usually ships in 2-12 days

0

9

Snapper 1716368

SWITCH, SEAT, GRAY, NC (TWIST IN)
(Superseded to 5100540)

$32.99

$

Usually ships in 2-12 days

0

10

Snapper 1960536

BOLT, HEX WASHER HEAD PLASTITE, 1/4 X 1/2
(Superseded to 1960536SM)

$4.99

$

Usually ships in 2-12 days

0

11

Snapper 5021199

CABLE TIE, PUSH MOUNT
(Superseded to 5021199SM)

$5.99

$

In Stock, only 1 left!

0

12

Snapper 5023222

CIRCUIT BREAKER, 20A
(Superseded to 5023222SM)

$23.99

$

In Stock, only 1 left!

0

13

Snapper 5025154

WASHER, 1/4 SAE
(Superseded to 84007033)

$4.49

$

Usually ships in 2-12 days

0

14

Snapper 2820438

NUT, HEX JAM, 5/16-24
(Superseded to 2820438SM)

$3.49

$

In Stock, only 2 left!

0

15

Snapper 5023217

WASHER, LIGHT LOCK, 5/16
(Superseded to 5023217SM)

$3.49

$

Usually ships in 2-12 days

0

16

Snapper 1686981

SOLENOID, 4 POLE 12 VOLT DC (TROMBETTA)
(Superseded to 1686981YP)

$28.99

$

In Stock, only 2 left!

0

17

Snapper 5025010X6

BOLT, 1/4-20 X 3/4" GD5 YZ
(Superseded to 5025010X6SM)

$3.99

$

In Stock, Qty 13

0

18

Snapper 5025126

NUT, 1/4-20 HEX SERR. FLANGE
(Superseded to 5025126FS)

$4.49

$

Usually ships in 2-12 days

0

19

Snapper 5021379

GROMMET, 7/8
(Superseded to 5021379SM)

$6.99

$

Usually ships in 2-12 days

0

20

Snapper 5021406

BATTERY CABLE, NEGATIVE, 22"
(Superseded to 5021406SM)

$16.99

$

Usually ships in 2-12 days

0

21

BATTERY, WET ( BCIU1, 340 CCA)

$

$

Not available

22

Snapper 5021542

BATTERY CABLE, POSITIVE, 30"
(Superseded to 5021542SM)

$29.99

$

In Stock, only 1 left!

0

23

Snapper 1722009

STRAP, BLACK RUBB
(Superseded to 1722009FS)

$9.99

$

In Stock, only 1 left!

0

24

Snapper 5022095

SWITCH, PLUNGER, N.O./N.C.
(Superseded to 1717050)

$17.99

$

In Stock, Qty 12

0

25

Snapper 7022886YP

SWITCH, PLUNGER, NO/NC SNAP-IN

$14.99

$

In Stock, Qty 20+

0
