38310 - Toro Power Shovel Snow Thrower (SN: 000000001 - 000999999) (1980) Rotor Housing Assembly Parts Diagram

Power Shovel Snow Thrower

Rotor Housing Assembly Parts Diagram

  • Title

1

Toro 218-505

See Supercession: 218-496
(Superseded to 218-496)

$

$

Not available

2

Toro 38-8120

See Supercession: 43-2590
(Superseded to 43-2590)

$

$

Not available

3

Toro 38-8440

DISCONTINUED

$

$

Not available

4

Toro 38-8490

DISCONTINUE

$

$

Not available

5

Toro 38-8350

DISCONTINUED

$

$

Not available

6

Toro 38-8130

DISCONTINUED

$

$

Not available

7

Toro 38-8140

DISCONTINUED

$

$

Not available

8

Toro 3250-20

SCREW-PPH

$6.99

$

In Stock, only 3 left!

0

9

Toro 32144-36

SCREW-PPH

$1.49

$

In Stock, Qty 20+

0

10

Toro 32104-118

SCREW-PPH

$

$

Not available

11

Toro 38-8550

DISCONTINUED

$

$

Not available

12

Toro 38-8250

DISCONTINUE

$

$

Not available

13

Toro 38-8570

DRIVE COUPLING

$

$

Not available

14

Toro 38-8450

DISCONTINUED

$

$

Not available

15

Toro 38-8560

DISCONTINUED

$

$

Not available

16

Toro 38-8540

DISCONTINUED

$

$

Not available

17

Toro 32144-35

See Supercession: 3250-18
(Superseded to 3250-18)

$

$

Not available

18

Toro 38-8240

DISCONTINUED PRC4

$

$

Not available

19

Toro 38-8460

DISCONTINUED

$

$

Not available

20

Toro 38-8370

DISCONTINUED

$

$

Not available

21

Toro 38-8110

DISCONTINUED

$

$

Not available

22

Toro 38-8580

FELT WASHER

$10.99

$

Usually ships in 3-6 days

0

23

Toro 3-6916

DISCONTINUED

$

$

Not available

24

Toro 3296-12

NUT-LOCK, NI

$1.49

$

In Stock, Qty 5

0

25

Toro 3296-54

NUT-LOCK

$5.49

$

Usually ships in 3-6 days

0

26

Toro 3250-19

SCREW-PPH

$2.49

$

In Stock, only 3 left!

0

27

Toro 3296-5

NUT-HEX

$3.99

$

In Stock, only 4 left!

0

28

Toro 3256-24

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

29

Toro 38-8170

ROTOR

$128.99

$

Usually ships in 3-6 days

0

30

Toro 38-8430

DISCONTINUED

$

$

Not available

31

Toro 38-8210

ROTOR PIN

$

$

Not available
