4000 - Poulan Chainsaw Chain Brake Parts Diagram

Chainsaw

Chain Brake Parts Diagram

  • Title

1

Poulan 25911

Handle- Actuating Arm

$

$

Not available

2

Poulan 15545

Screw-Handle

$

$

Not available

3

Poulan 11769

Bar Clamp Actuating Arm Ass'y.

$

$

Not available

4

Poulan 15415

Screw-Adjusting

$

$

Not available

5

Poulan 25044

Pin - Bar Adjusting

$

$

Not available

6

Poulan 24419

"E" Ring

$

$

Not available

7

Poulan 15385

Screw - Bar Adjusting

$

$

Not available

8

Poulan 24901

Guard

$

$

Not available

9

Poulan 15439

Retaining Ring

$

$

Not available

10

Poulan 15217

Nut-H10-24

$

$

Not available

11

Poulan 25914

Shield - Heat

$

$

Not available

12

Poulan 15406

Screw - #10 - 24 x 1/2

$

$

Not available

13

Poulan 1543

Nut-#10-24

$

$

Not available

14

Poulan 10291

Clutch

$

$

Not available

A

Poulan 26372

Decal - Warning

Note: Decals

$

$

Not available

B

Poulan 26341

Decal - Instruction (Heat Shield)

Note: Decals

$

$

Not available

Poulan 24768

Decal - Bar Clamp

Note: Decals

$

$

Not available
