40113 - Toro Walk-Behind Mower (SN: 008000001 - 008999999) (1968) Engine. Recoil Start Model 81302 (part 1) Parts Diagram

Walk-Behind Mower

Engine. Recoil Start Model 81302 (part 1) Parts Diagram

  • Title

1

Toro 220859

Locknut-Muffier

$

$

Not available

2

Toro 294441

Muffler-Exhaust

$

$

Currently unavailable

3

Toro 230194

Rod-Control

$

$

Currently unavailable

4

Toro 220754

Support, Tube

$

$

Currently unavailable

5

Toro 230346

Tube, Breather

$

$

Currently unavailable

6

Toro 66578

Grommet

$

$

Currently unavailable

7

Toro 93062

Screw, Sem

$

$

Currently unavailable

8

Toro 66432

Washer-Plain

$

$

Currently unavailable

9

Toro 294178

Breather-Valve Chamber

$

$

Currently unavailable

10

Toro 92870

Screw, Breather Mtg. Stem

$

$

Currently unavailable

11

Toro 27549

Gasket Breather

Note: Included in Gasket Set, Part No. 294244

$

$

Currently unavailable

12

Toro 294502

Bracket, Control Wire Casing

$

$

Currently unavailable

13

Toro 230253

Stop, Control Rod

$

$

Currently unavailable

14

Toro 220730

Clip-Control Rod

$

$

Currently unavailable

15

Toro 210810

61762/95-5929-5 WHE

$3.23

$

Usually ships in 3-6 days

0

16

Toro 93329

Screw, Carburetor and Intake Elbow Mounting Stem

$

$

Currently unavailable

17

Toro 26925

Spring-Governor

$

$

Currently unavailable

18

Toro 68987

Gasket-Carburetor

Note: Included in Gasket Set, Part No. 294244

$

$

Currently unavailable

19

Toro 27355

Gasket-Carburetor

Note: Included in Gasket Set, Part No. 294244

$

$

Currently unavailable

20

Toro 26478

1531A GIL 3 1/2HP T

$3.23

$

Usually ships in 3-6 days

0

21

Toro 260552

Spring-Valve

$

$

Currently unavailable

22

Toro 91249

Plug-Pipe

$

$

Currently unavailable

23

Toro 230173

Tappet-Valve

$

$

Not available

24

Toro 260257

Crankshaft

$

$

Currently unavailable

25

Toro 210453

Gear-Cam
(Superseded to 740280)

$23.99

$

Usually ships in 3-6 days

0

26

Toro 294305

Cover Assy.-Crankcase

$

$

Currently unavailable

27

Toro 27586

Gasket-Crankcase" thick (Standard)

Note: Included in Gasket Set, Part No. 294244

$

$

Currently unavailable

Toro 27617

Gasket-Crankcase .005" thick

Note: Included in Gasket Set, Part No. 294244

$

$

Currently unavailable

Toro 27618

Gasket-Crankcase .009" thick

Note: Included in Gasket Set, Part No. 294244

$

$

Currently unavailable

28

Toro 66768

Plug-Oil

$

$

Currently unavailable

29

Toro 93032

Screw

$

$

Currently unavailable

30

Toro 293708

Bushing

$

$

Currently unavailable

31

Toro 89660

Seal-Oil

$

$

Currently unavailable

32

Toro 294367

Rod Assy.-Connecting

$

$

Currently unavailable

33

Toro 220670

Dipper-Conn. Rod

$

$

Currently unavailable

34

Toro 220756

Lock, Conn Rod Screw

$

$

Currently unavailable

35

Toro 92296

Screw, Conn.Rod

$

$

Currently unavailable

36

Toro 220478

Muffler-Exhaust

$

$

Currently unavailable

37

Toro 93042

Screw

$

$

Currently unavailable

38

Toro 291925

Pin Assy., Piston, Standard

$

$

Currently unavailable

Toro 291926

Pin Assy., Piston, .005" O.S.

$

$

Currently unavailable

39

Toro 26026

Iock-Piston Pin

$

$

Currently unavailable

40

Toro 296676

Valve Exhaust

$

$

Currently unavailable

41

Toro 93312

Gear-Cam

$

$

Currently unavailable

Toro 23184

Retainer-Valve Spring
(Superseded to 742655)

$

$

Not available

Toro 23187

1404A SNW W/23755/2

$3.23

$

Usually ships in 3-6 days

0

42

Toro 296677

Valve Intake

$

$

Currently unavailable

43

Toro 29806

Gasket-Spark Plug

$

$

Currently unavailable

44

Toro 29693

Plug, Spark (with Gasket)

$

$

Currently unavailable

45

Toro 220884

Switch-Stop

$

$

Not available

46

Toro 220581

Cover-Cylinder Head

$

$

Currently unavailable

47

Toro 92674

Screw, Cylinder Head

$

$

Currently unavailable

48

Toro 91386

Screw-Cylinder Head

$

$

Currently unavailable

49

Toro 22963

Washer

$

$

Currently unavailable

50

Toro 210812

Head-Cylinder

$

$

Currently unavailable

51

Toro 27670

Gasket-Cylinder Hd.

Note: Included in Gasket Set, Part No. 294244

$

$

Currently unavailable

52

Toro 295455

Piston Assy., Standard

$

$

Currently unavailable

Toro 295456

Piston Assy., .010" O.S.

$

$

Currently unavailable

Toro 295457

Piston Assy., .020" O.S.

$

$

Currently unavailable

Toro 295458

Piston Assy., .030" O.S.

$

$

Currently unavailable

53

Toro 295657

Ring Set-Standard Piston Consists of: No. 210796 Ring, Piston, Compression, Top, Std. No. 210797 Ring, Piston, Compression, Ctr, Std. No. 295661 Ring, Oil (w/expander) Std.

$

$

Currently unavailable

Toro 295658

Ring Set-.010" O.S. Piston Consists of: No. 210799 Ring, Piston, Compression, Top, .010" O.S. No. 210798 Ring, Piston, Compression, Ctr, .010" O.S. No. 295662 Ring, Oil(w/expander) .010" O.S.

$

$

Currently unavailable

Toro 295659

Ring Set-.020" O.S. Piston Consists of: No. 210801 Ring, Piston, Compression, Top, .020" O.S. No. 210800 Ring, Piston, Compression, Center, .020" O.S. No. 295663 Ring, Oil (w/expander) .020" O.S.

$

$

Currently unavailable

Toro 295660

Ring Set-. 030" O.S. Piston Consists of: No. 210803 Ring, Piston, Compression, Top, .030" O.S. No. 210802 Ring, Piston, Compression, Ctr, .030" O.S. No. 295664 Ring, Oil (w/expander) .030" O.S.

$

$

Currently unavailable
