41-20OE02 (520-H) - Toro Garden Tractor (SN: 010000001 - 019999999) (1991) TORO POWER PLUS STARTER COMPONENTS Parts Diagram

Garden Tractor

TORO POWER PLUS STARTER COMPONENTS Parts Diagram

  • Title

1

Toro 62-2760

Kit, Hardware-Starter (Includes (2) Solenoid Mtg Screws, 2 Thru Bolts, Armature Shims, Pinion Collar and Retaining Ring)

$

$

Not available

2

Toro 62-2720

Kit, Solenoid-Starter (Includes Solenoid and Spring Plunger)
(Superseded to 72-3930)

$

$

Not available

3

Toro NN10262

Kit, Bushing-Starter (Includes Rear Cap with Bushing and Front Bushing)
(Superseded to 62-2730)

$

$

Not available

4

Toro NN-10264

Holder, Brush (Includes Negative Brush)

$

$

Currently unavailable

5

Toro NN10263

Kit, Brush-Starter (Includes (2) Negative and (1) Positive Brushes)
(Superseded to 62-2740)

$

$

Not available

6

Toro NN10266

Kit, Shift Lever-Starter (Includes Lever, Wear Plate and Rubber Plug)
(Superseded to 62-2770)

$

$

Not available

7

Toro NN10270

Clutch Assembly, Starter (Includes Pinion Gear)
(Superseded to 72-3940)

$

$

Not available

8

Toro NN10271

Dust Seal
(Superseded to NN10886)

$

$

Not available

9

Toro 79-6300

SPRING-BRUSH

$

$

Not available
