4181 E94 - Electrolux/AYP Lawn Tractor (1999) ENGINE Parts Diagram

Lawn Tractor

ENGINE Parts Diagram

  • Title

1

Electrolux/AYP 52-098-03

STARTER ASSY

$

$

Not available

2

Kohler X-20-1

WASHER
(Superseded to X-20-1-S)

$3.99

$

Usually ships in 2-5 days

0

3

Kohler X-81-1

NUT
(Superseded to 25 100 20-S)

$3.49

$

In Stock, only 1 left!

0

4

Electrolux/AYP 52-755-05

KIT, DRIVE

$

$

Not available

5

Electrolux/AYP 52-755-08

KIT, DRIVE PARTS

$

$

Not available

6

Electrolux/AYP 52-227-01

CAP, DRIVE END

$

$

Not available

7

Electrolux/AYP 52-170-02

ARMATURE

$

$

Not available

8

Electrolux/AYP 52-211-01

BOLT

$

$

Not available

9

Kohler 277612

CAP, COMMUTATOR END
(Superseded to 52 227 10-S)

$341.99

$

Usually ships in 2-5 days

0

10

Electrolux/AYP 48-755-15

KIT, BRUSH

$

$

Not available

11

Kohler 237878

KIT
(Superseded to 237878-S)

$149.99

$

In Stock, Qty 10

0

12

Kohler X-67-51

SCREW
(Superseded to X-67-51-S)

$3.49

$

Usually ships in 2-5 days

0

13

Electrolux/AYP 52-025-36

FLYWHEEL

$

$

Not available

14

Electrolux/AYP 52-468-15

WASHER

$

$

Not available

15

Electrolux/AYP 25-086-24

SCREW, 3/8-24X1-1/4

$

$

Not available

16

Kohler X-286-17

KEY
(Superseded to X-286-17-S)

$3.49

$

In Stock, only 2 left!

0

17

Electrolux/AYP 25-157-01

FAN

$

$

Not available

18

Electrolux/AYP 25-112-04

SPACER

$

$

Not available

19

Electrolux/AYP 25-086-21

SCREW, HEX 1/4-20 X 5/8

$

$

Not available

20

Kohler 237373

SHAFT, FRONT DRIVE
(Superseded to 25 029 04-S)

$

$

Not available

21

Kohler X-159-2

SCREW
(Superseded to X-159-2-S)

$4.49

$

Usually ships in 2-5 days

0

22

Electrolux/AYP 25-162-02

SCREEN, GRASS

$

$

Not available

Electrolux/AYP 25-450-03

TAG CAUTION

$

$

Not available
