425601x53B - Murray 42" Lawn Tractor (2001) Rear Chassis Assembly Parts Diagram

42" Lawn Tractor

Rear Chassis Assembly Parts Diagram

  • Title

1

Murray 095415MA

SEAT

$433.99

$

Usually ships in 2-12 days

0

2

Murray 094629E700

SEAT DECK

$

$

Currently unavailable

4

Murray 690424MA

CONTAINER, BATTERY

$45.99

$

In Stock, only 1 left!

0

5

Murray 26X263MA

SCREW, 1/4-20X .63

$4.99

$

In Stock, only 1 left!

0

6

Murray 094886E701

PLATE, LIFT

$53.99

$

Usually ships in 2-12 days

0

7

Murray 009X56MA

BOLT, SHOULDER

$3.49

$

Usually ships in 2-12 days

0

8

Murray 26X270

SCREW, 10-24X.500
(Superseded to 26X270MA)

$4.49

$

In Stock, only 3 left!

0

9

Murray 094154E700

SUPPORT, SEAT

$

$

Currently unavailable

10

Murray 094156ZMA

HINGE, SEAT PIVOT

$7.99

$

Usually ships in 2-12 days

0

11

Murray 028X23MA

NUT, PUSH CAP
(Superseded to 703948)

$4.49

$

In Stock, Qty 12

0

12

Murray 164X31

SPRING, COMPRESSION
(Superseded to 164X31MA)

$7.99

$

In Stock, only 2 left!

0

13

Murray 009X55MA

BOLT, SHOULDER

$3.49

$

Usually ships in 2-12 days

0

14

Murray 094155 Z

WASHER, CUP

$

$

Currently unavailable

15

Murray 015X89MA

NUT, 1/4-20

$4.49

$

Usually ships in 2-12 days

0

16

Murray 164X30MA

SPRING, COMPRESSION

$15.99

$

Usually ships in 2-12 days

0

17

Murray 26X249MA

SCREW

$

$

Not available

20

Murray 1001054MA

BOLT, WING

$6.99

$

Usually ships in 2-12 days

0

21

Murray 017X47MA

Washer
(Superseded to 704015)

$4.49

$

Usually ships in 2-12 days

0

22

Murray 094469

COVER, DETENT

$43.99

$

Usually ships in 2-12 days

0

24

Murray 26X284MA

SCREW

$3.99

$

Usually ships in 2-12 days

0

25

Murray 17X207

WASHER

$

$

Not available

26

Murray 094057MA

SPRING - LEAF

$5.99

$

Usually ships in 2-12 days

0

27

Murray 26X229MA

SCREW, 1/4-20X.50

$4.49

$

In Stock, only 1 left!

0

32

Murray 094153E700MA

BRACKET, PIVOT SEAT
(Superseded to 1001648E701MA)

$42.99

$

Usually ships in 2-12 days

0

33

Murray 001X45MA

BOLT, 5/16-18X.75
(Superseded to 703822)

$4.49

$

In Stock, only 2 left!

0

34

Murray 015X88MA

NUT, 5/16-18
(Superseded to 704067)

$3.99

$

In Stock, Qty 20+

0

35

Murray 015X81MA

NUT, #10-24

$4.99

$

Usually ships in 2-12 days

0
